Product Details
Introduction
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Includes: Ethernet patch cable, Rack mounting brackets, Rack mounting support rails, Screw, USB cable, Washer
RoHS
Features
UPS topology
Line-Interactive
Output power capacity
2.2 kVA
Output power
1980 W
Waveform
Sine
Input operation voltage (min)
160 V
Input operation voltage (max)
286 V
Input frequency
50/60 Hz
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Output frequency
50/60 Hz
Automatic Voltage Regulation (AVR)
Yes
Surge energy rating
739 J
Response time
6 ms
Crest factor
3:1
Emergency Power Off (EPO)
Yes
Noise level
55 dB
Audible alarm(s)
Yes
Ports & interfaces
AC outlet types
C13 coupler, C19 coupler
Power plug
C20 coupler
AC outlets quantity
9 AC outlet(s)
USB port
Yes
Serial interface
Yes
Emergency Power Off (EPO) connector
Yes
SmartSlot
Yes
SmartConnect port
Yes
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery recharge time
2 h
Hot-swap battery
Yes
Automatic battery test
Yes
Design
Form factor
Rackmount/Tower
Rack capacity
2U
Product colour
Black, Grey
Display type
LCD
LED indicators
Yes
International Protection (IP) code
IP20
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 7620 m
Technical details
Sustainability compliance
Yes
Sustainability certificates
RoHS
Compliance certificates
RoHS
Weight & dimensions
Width
432 mm
Depth
683 mm
Height
86 mm
Weight
33.3 kg
Package width
600 mm
Package depth
980 mm
Package height
458 mm
Package weight
41.5 kg
Packaging data
Rack mount kit
Yes
Cables included
RJ-45, USB cable
Other features
Nominal output voltage
230 V
Nominal input voltage
230 V
Packaging content
Management card included
Yes
Information
| Part Number: | SMTL2200RMI2UCNC |
