Introduction
The ViewSonic PA503S price-performance projector features 3,600 lumens, native SVGA 800 x 600 resolution, and intuitive, user-friendly design. Exclusive SuperColor technology offers a wide color gamut for beautiful image production in nearly any environment. The PA503S also features extensive connectivity including HDMI, 2 x VGA, VGA out, Composite Video and audio in/out. An energy-saving SuperEco feature reduces power consumption and extends the lamp life by up to 15,000 hours. With advanced audio-visual features, flexible connectivity options, and an affordable price, the PA503S is ideal for use in education and small business environments.
3D Blu-ray Ready
HDMI Input
Equipped with the latest HDMI, this projector is perfect for connecting to any HDMI-enabled device, and can display 3D images directly from 3D Blu-ray players. 3D images can be viewed with optional ViewSonic PGD-350 Shutter Glasses, or any other compatible 3D glasses.
Quick Power Off
With the Quick Power Off feature enabled, the projector can be quickly powered off in seconds rather than waiting for a cool-down cycle to complete. This lets users pack the projector away without having to worry about the internal fan still running.
Industry-leading Warranty
ViewSonic offers one of the industry's best overall projector warranties with 3-year limited parts and labor, 1-year lamp, and first year free Express Exchange service for an added value worth up to $150.
Logistics data
Pallet gross length
74 cm
Pallet gross width
90 cm
Pallet gross height
2.21 m
Products per master (outer) case
1 pc(s)
Harmonized System (HS) code
8528620000
Design
Market positioning
Business
Product type
Standard throw projector
Product colour
Grey, White
Placement
Desktop
Cable lock slot
Y
Cable lock slot type
Kensington
Projector
Screen size compatibility
762 - 7620 mm (30 - 300")
Projection distance
1.1 - 13 m
Projector brightness
3600 ANSI lumens
Projection technology
DLP
Projector native resolution
SVGA (800x600)
Native aspect ratio
4:3
Number of colours
1.073 billion colours
Horizontal scan range
15 - 102 kHz
Vertical scan range
23 - 120 Hz
Keystone correction, vertical
-40 - 40°
Matrix size
1.4 cm (0.55")
Matrix type
DMD
Light source
Light source type
Lamp
Service life of light source
4500 h
Service life of light source (economic mode)
15000 h
Lamp power
190 W
Lamps quantity
1 lamp(s)
Lens system
Focus
Manual
Zoom capability
Y
Zoom type
Manual
Optical zoom
1.1x
Throw ratio
1.96 - 2.15:1
Video
Analog signal format system
NTSC,PAL,PAL 60,SECAM
3D Ready
Y
Supported graphics resolutions
640 x 480 (VGA),720 x 480,720 x 576,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1360 x 768 (WXGA),1366 ? 768,1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1920 x 1200 (WUXGA)
Supported video modes
480i,480p,576i,576p,720p,1080i,1080p
Ports & interfaces
HDMI connector type
Full-size
HDMI version
1.4
Serial interface type
RS-232
PC Audio in
Y
PC Audio out
Y
VGA (D-Sub) ports quantity
3
HDMI ports quantity
1
Composite video in
1
DVI port
N
AC (power) in
Y
Network
Storage
Features
Certification
FCC (ICES-003), cTUVus
Multimedia
Built-in speaker(s)
Y
RMS rated power
2 W
Number of built-in speakers
1
Display
Power
Power source
AC
Power consumption (typical)
260 W
Power consumption (standby)
0.5 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90%
Operating altitude
0 - 1499 m
Weight & dimensions
Width
294 mm
Depth
110 mm
Height
218 mm
Weight
2.2 kg
Package width
365 mm
Package depth
188 mm
Package height
300 mm
Package weight
3.24 kg
Packaging content
Remote control included
Y
Cables included
AC, VGA
Quick start guide
Y
Other features
