Product Details
Features
Module type
Analog
Signal direction
Input/output
Channel type
Relay channel
Serial interface type
RS-422/485
Ethernet LAN (RJ-45) ports
1
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS1, HTTP/ 2, TLS1, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB- II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
LED indicators
Yes
International Protection (IP) code
IP30
Certification
CSA, UL/cUL, CE, KC, VCCI, RCM
Packaging data
Quantity per pack
1 pc(s)
Power
DC input voltage
10 - 28 V
Operational conditions
Operating temperature (T-T)
-40 - 70 °C
Storage temperature (T-T)
-40 - 70 °C
Relative humidity
10 - 85%
Weight & dimensions
Width
99 mm
Depth
118 mm
Height
42 mm
Weight
445 g
Logistics data
Quantity per pack
1 pc(s)
Information
| Part Number: | 03037-001 |
