STARTECH.COM USB-c Dual-dp Multiport Hub - 100w Pd 2x 4k 60hz Gbe

£51.46

Part Number: 189B-USBC-MULTIPORT
Delivery: 1 - 2 days

Product Details

Introduction

Create a mobile workstation wherever you work

Enable dual-4K displays, high-speed device connectivity, power, and networking from a single USB-C dock for consistent productivity anywhere.

Deploy Multi-Display Setups with Ease

Drive two 4K 60Hz DisplayPort displays on Windows, Linux, and ChromeOS to increase screen real estate. Ideal for hot desks and remote users who need instant multi-monitor setups.

Connect Devices and Keep Ports Free

Connect modern and legacy high-speed devices with 3x USB-C and 2x USB-A (5Gbps), while a dedicated USB-A 2.0 port handles keyboard and mouse dongles or other essential peripherals. Reduce hub sprawl and keep critical ports available for storage, capture, or field tools.

Deliver a Consistent Desktop Experience Anywhere

Provide 100W PD charging passthrough and Gigabit Ethernet for stable, wired performance at home, in the office, or while travelling. Standardize deployments with the same display, USB, and network experience to simplify rollouts and support.

Built for Sustainability, Designed for Performance

This hub features a housing made from 85% post-consumer recycled (PCR) plastic. The product also ships in FSC Mix packaging made from responsibly sourced materials. These materials help align your IT infrastructure with your organization's sustainability goals, without compromising on quality or durability.

Ports & interfaces

Connectivity technology Wired
Host interface USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity 1
USB 2.0 Type-C ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 3
USB Power Delivery (USB PD) Yes
USB Power Delivery up to 100 W
DisplayPorts quantity 2
DisplayPort version 1.2
Microphone in No

Network

Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Ethernet LAN data rates 10,100,1000 Mbit/s
Wake-on-LAN ready Yes
Full duplex Yes

Performance

Card reader integrated No
Data transfer rate 5 Gbit/s
HD type 4K Ultra HD
Maximum digital resolution 3840 x 2160 pixels
Product colour Grey
Housing material Plastic
Mean time between failures (MTBF) 103855 h

Power

Output voltage 5 V
Power consumption (typical) 15 W
USB cable length 0.3 m

Software

Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64
Linux operating systems supported Yes
Other operating systems supported ChromeOS

Operational conditions

Operating temperature (T-T) 0 - 70 °C
Storage temperature (T-T) 10 - 70 °C
Operating relative humidity (H-H) 10 - 85%

Weight & dimensions

Width 55 mm
Depth 150 mm
Height 16.5 mm
Weight 100 g

Packaging data

Package width 193 mm
Package depth 117 mm
Package height 24 mm
Package weight 190 g

Packaging content

User guide Yes

Logistics data

Products per master (outer) case 80 pc(s)
Master (outer) case width 540 mm
Master (outer) case length 425 mm
Master (outer) case height 270 mm

Other features

Chipset Synaptics - VMM5220, VIA - VL103, VIA - VL817S, Realtek - RTL8153E

Information

Part Number: 189B-USBC-MULTIPORT
