Product Details
Network
Ethernet LAN
Yes
LAN controller
Dragon RTL8125BG
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
Wi-Fi
Yes
Bluetooth
Yes
Bluetooth version
5.3
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
DisplayPorts quantity
1
DisplayPort version
1.4
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
USB 2.0 ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
HDMI ports quantity
1
HDMI version
2.1
Thunderbolt 4 ports quantity
1
Design
Cable lock slot type
Kensington
Product colour
Silver
Housing material
Aluminium
Product type
PC barebone
Processor
Processor manufacturer
Intel
Processor family
Intel Core Ultra 5
Processor model
125H
Processor cores
14
Processor threads
18
Processor frequency
1.2 GHz
Performance cores
4
Efficient cores
8
Low Power Efficient-cores
2
Performance-core Max Turbo Frequency
4.5 GHz
Efficient-core Max Turbo Frequency
3.6 GHz
Low Power Efficient-core Max Turbo Frequency
2.5 GHz
Performance-core base frequency
1.2 GHz
Low Power Efficient-core Base Frequency
700 MHz
Built-in processor
Yes
Processor cache
18 MB
ECC supported by processor
No
Memory
Memory slots type
SO-DIMM
Number of memory slots
2
Maximum internal memory
96 GB
Supported memory types
DDR5-SDRAM
ECC
No
Non-ECC
Yes
Storage
Supported storage drive types
HDD & SSD
Storage drive sizes supported
M.2
SSD form factor
M.2
Storage drive interface
PCI Express, Serial ATA
NVMe
Yes
Graphics
On-board graphics card
Yes
Graphics card family
Intel
Software
Windows operating systems supported
Windows 11
Linux operating systems supported
RedHat EL Linux, Ubuntu 24.04 LTS
Power
Power supply type
External AC adapter
Power supply
65 W
AC adapter output voltage
19 V
AC adapter output current
3.42 A
Weight & dimensions
Width
135 mm
Depth
115 mm
Height
36 mm
Other features
Warranty period
3 year(s)
Information
| Part Number: | 90AR00M2-M000M0 |
