Introduction
45’’ Dual QHD VA panel with KVM switch, USB-C dock and RJ45 (LAN) and height adjustable stand
The XCB4594DQSN features a 1500R curved VA panel with a 165Hz refresh rate, 0.8ms MPRT, and a 5120x1140 (DQHD) resolution for superb image quality. The KVM switch allows you to connect multiple computers that can be operated over one console (monitor, keyboard, mouse). The USB-C dock simplifies setup with one cable for laptop signal transmission, power, and charging. Connecting to the Internet via LAN automatically links your notebook to the network. The VA panel ensures expansive viewing angles and vivid colours, and the 1500R curvature minimizes eye strain for a lifelike and fully immersive gaming experience. The dual QHD resolution provides sharp visuals, and the height-adjustable stand adds a comfortable and highly ergonomic experience.
DQHD
Ultra-wide 32:9 monitors with a DQHD 5120x1440 resolution, also called dual QHD, deliver razor-sharp images. They make it possible to divide the workspace into multiple windows and simultaneously open all the documents you need.
CURVED DESIGN 1500R
The 1500R curvature of the screen reduces the strain on your eyes while providing a realistic viewing experience. It allows a comprehensive and more natural viewing angle than you’ll have with flat monitors lined up side by side. The result is a more immersive experience which boosts productivity and focus whether it be for work, gaming, entertainment, editing or more.
USB-C DOCK
The dock allows you to connect your laptop with a single cable to the monitor to both make sure it is charged and connected to a wired network and signal from the laptop is sent to the monitor. With additional USB-ports, your mouse, keyboard or webcam can also be connected to the monitor. All thanks to a single cable connecting your laptop* to the USB C dock in the monitor.
KVM SWITCH
Having a monitor with a KVM switch allows you to share the devices connected via USB to your monitor with two different PCs. Just change the signal input in the OSD menu of the monitor and your keyboard, mouse and webcam will switch from your work laptop to your gaming PC.
VA
VA panel technology offers higher contrast, darker blacks and much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it.
Display
Response time (MPRT)
0.8 ms
Display number of colours
16.7 million colours
Horizontal scan range
30 - 260 kHz
DDC/CI
Yes
Colour depth
8 bit
sRGB coverage (typical)
100%
NTSC coverage (typical)
80%
Display diagonal
114.3 cm (45")
Display resolution
5120 x 1440 pixels
HD type
Dual QHD
Native aspect ratio
32:9
Display technology
LED
Panel type
VA
Backlight type
LED
Touchscreen
No
Display brightness (typical)
450 cd/m˛
Response time
0.8 ms
Display surface
Matt
Screen shape
Curved
Screen curvature rating
1500R
Contrast ratio (typical)
3000:1
Contrast ratio (dynamic)
80000000:1
Maximum refresh rate
165 Hz
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Pixel pitch
0.212 x 0.212 mm
Viewable size, horizontal
30.6 cm
Viewable size, vertical
108.8 cm
Digital horizontal frequency
30 - 260 kHz
Display diagonal (metric)
113 cm
High Dynamic Range (HDR) supported
Yes
High Dynamic Range (HDR) technology
High Dynamic Range (HDR) 400
Ports & interfaces
USB upstream port type
USB Type-C
Number of USB Type-C upstream ports quantity
1
Built-in USB hub
Yes
USB hub version
3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity
3
USB Type-C downstream ports quantity
1
USB Power Delivery
Yes
USB Power Delivery up to
90 W
HDMI
Yes
HDMI ports quantity
2
DisplayPorts quantity
1
Headphone out
Yes
Headphone outputs
1
Built-in KVM switch
Yes
KVM switch ports quantity
1
HDCP
Yes
DC-in jack
Yes
Number of downstream ports
3
Ergonomics
Cable management
Yes
VESA mounting
Yes
Panel mounting interface
200 x 100 mm
Wall mountable
Yes
Cable lock slot
Yes
Cable lock slot type
Kensington
Height adjustment
Yes
Height adjustment
13 cm
Tilt adjustment
Yes
Tilt angle range
3 - 20°
On Screen Display (OSD)
Yes
On Screen Display (OSD) languages
Czech, German, English, French, Hungarian, Italian, Japanese, Polish, Russian
Number of OSD languages
9
Weight & dimensions
Height (without stand)
409 mm
Width (with stand)
1090 mm
Depth (with stand)
275 mm
Height (with stand)
409 mm
Weight (with stand)
11.2 kg
Performance
AMD FreeSync
Yes
Brand specific technologies
Black Equalizer, Eye Saver
ConnectShare (USB)
Yes
Flicker-free technology
Yes
Low Blue Light technology
Yes
Multimedia
Built-in speaker(s)
Yes
Built-in camera
No
Number of speakers
2
RMS rated power
6 W
Design
Market positioning
Gaming
Product colour
Black
Detachable stand
Yes
Feet colour
Black
Technical details
Native refresh rate
60 Hz
Network
Power
Energy efficiency class (SDR)
F
Energy efficiency class (HDR)
G
Energy consumption (SDR) per 1000 hours
37 kWh
Energy consumption (HDR) per 1000 hours
67 kWh
Power consumption (typical)
37 W
Power consumption (standby)
0.5 W
Power consumption (off)
0.3 W
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power supply type
External
Energy efficiency scale
A to G
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Packaging content
Stand included
Yes
Cables included
DisplayPort, HDMI, Power, USB
Power adapter included
Yes
Quick start guide
Yes
Manual
Yes
Packaging data
Package width
1260 mm
Package depth
315 mm
Package height
470 mm
Package weight
16.4 kg
Sustainability
Sustainability compliance
Yes
Sustainability certificates
CE, ErP, PSE, REACH, RoHS, TUV, UKCA, VCCI, WEEE
European Product Registry for Energy Labelling (EPREL) code
1774068
Other features
User controls
picture (brightness, contrast, black tuner, sharpness, OD, ACR, ECO Mode, X-Res technology), colour (warm, normal, cool, user colour, i-Style colour, blue light reducer), input select, PBP (PBP mode, sub win input, PBP swap, audio input), audio (volume, mute), language, OSD settings (OSD H. position, OSD V. position, OSD background, OSD time out, information), setup menu 1 (MST, DSC, KVM, USB-C, USB BC), setup menu 2 (video mode adjust, HDMI RGB range, direct drive, adaptive sync, MBR, HDR, opening logo, LED, memory recall)
Packaging content
quick start guide, safety guide
Weight
11.2 kg
Width
1090 mm
Depth
275 mm
Control panel
Navigation (power) button: Center (Menu/Execution), Down (i-Style Colour), Up (Input Select), Right (Volume), Left (ECO Mode), Power
Volume control
Buttons
Ethernet LAN (RJ-45) ports
1
Compliance certificates
CE, PSE, REACH, RoHS, cTUVus, UKCA, VCCI, WEEE
