Product Details
Introduction
The Multi Mode OM3 cables are designed to support high transfer speed, the cables are capable of supporting up to 10gigabit applications at the same time being backward compatible with 50/125 OM2 infrastructure. The cables meet or exceed industry standard specifications; each cable is individually tested for maximum reliability and comes with performance reports.The ALOGIC OM3 Patch Cables are available in various lengths starting from 0.5m to 100m length
Features
Cable length
1.5 m
Connector 1
LC
Connector 2
LC
Connector 1 gender
Male
Connector 2 gender
Male
Fibre optic type
OM3
Product colour
Turquoise
Full duplex
Yes
Core diameter
50 µm
Cladding diameter
125 µm
Fiber mode structure
Multi-mode
Wavelengths supported
850,1300 nm
Ethernet interface type
10 Gigabit Ethernet
Data transfer rate
10 Gbit/s
Insertion loss
0.2 dB
Jacket material
Low smoke zero halogen (LSZH)
Certification
ETL/c-ETL
Weight & dimensions
Cable diameter
2 mm
Packaging data
Quantity per pack
1 pc(s)
Logistics data
Harmonized System (HS) code
85447000
Other features
Number of optical fibres
2
Information
| Part Number: | LCLC-15-OM3 |
