Product Details
Introduction
Antimicrobial, Waterproof, Drop Protection
Scanning
Type
Handheld bar code reader
Scanner type
1D/2D
Sensor type
CMOS
Linear (1D) barcodes supported
Codabar,Code 11,Code 128,Code 25 (IR 2 of 5),Code 25 (non-IR 2 of 5),Code 39,Code 93,EAN-13,EAN-8,GS1 DataBar,GS1-128 (UCC/EAN-128),MSI,Plessey,UPC-A,UPC-E
2D (matrix & stacked) barcodes supported
Data Matrix, Micro QR Code, PDF417, QR Code
Optical sensor resolution (W x H)
640 x 480 pixels
Working distance
30 cm
Light levels (direct sunlight)
0 - 100000 lx
Wavelength
650 nm
Tilt reading angle
-50 - 50°
Pitch reading angle
-45 - 45°
Yaw reading angle
-360 - 360°
Maximum scan width
0.254 mm
Motion tolerance (cm/s)
60.96
Ports & interfaces
Connectivity technology
Wireless
Standard interfaces
RF Wireless
Operating frequency
2400 MHz
Cable length
1.83 m
Performance
Housing material
Plastic, Silicone
International Protection (IP) code
IP67
Protection features
Shock resistant, Waterproof
LED indicators
Y
Buzzer
Y
Product colour
Black, Yellow
Country of origin
China
Certification
FCC, CE
Power
Power source type
Battery
Input voltage
5 V
Power consumption
220 mA
Weight & dimensions
Width
72 mm
Depth
100 mm
Height
175 mm
Weight
160 g
Packaging data
Package width
266.7 mm
Package depth
182.8 mm
Package height
114.3 mm
Package weight
907 g
Operational conditions
Operating temperature (T-T)
-20 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Technical details
Sustainability certificates
RoHS
Other features
Compatible operating systems
Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP, Mac OS X
Information
| Part Number: | NUSCAN 5200TR |
