Product Details
Introduction
AMD Ryzen™ 7 8700G with AMD Ryzen AI is the ultimate all-in-one desktop processor with AMD Radeon™ 780M Graphics capabilities
Processor
Processor manufacturer
AMD
Processor generation
AMD Ryzen 8000 Series
Processor model
8700G
Processor base frequency
4.2 GHz
Processor family
AMD Ryzen™ 7
Processor cores
8
Processor socket
Socket AM5
Processor lithography
4 nm
Processor threads
16
Processor operating modes
64-bit
Processor boost frequency
5.1 GHz
Processor cache
16 MB
Processor cache type
L3
Thermal Design Power (TDP)
65 W
Configurable TDP-up
65 W
Package type
Box
Cooler included
Yes
Configurable TDP-down
45 W
Neural processor unit (NPU)
Neural processor unit (NPU)
AMD Ryzen AI
NPU performance up to
16 TOPs
Memory
Maximum internal memory supported by processor
256 GB
Memory types supported by processor
DDR5-SDRAM
Memory clock speeds supported by processor
3600,5200 MHz
Memory channels
Dual-channel
Graphics
On-board graphics card
Yes
Discrete graphics card
No
On-board graphics card model
AMD Radeon 780M
On-board graphics card outputs supported
DisplayPort 2.1, HDMI 2.1
On-board graphics card base frequency
2900 MHz
On-board graphics card DirectX version
12.0
On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
Discrete graphics card model
Not available
Features
Market segment
Desktop
Maximum number of PCI Express lanes
20
PCI Express slots version
4.0
Supported instruction sets
AES, AVX, AVX 2.0, AVX-512, MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSSE3
Compatible operating systems
Windows 10/11 x64, RHEL x86 64-bit, Ubuntu x86 64-bit
I/O configuration
USB ports quantity
5
Information
| Part Number: | 100-100001236SBX |
