Product Details
Introduction
Features:
Single input power source
Toolless Mounting Capabilities
Vertical Mounting Capabilities
Weight & dimensions
Width
56 mm
Depth
44 mm
Height
1619 mm
Dimensions (WxDxH)
56 x 44 x 1619 mm
Weight
5.57 kg
Packaging data
Package width
152 mm
Package depth
127 mm
Package height
2134 mm
Package dimensions (WxDxH)
152 x 127 x 2134 mm
Package weight
6.48 kg
Design
PDU types
Basic
Type
Single-phase
Rack capacity
0U
Mounting
Vertical
Product colour
Black
Ports & interfaces
AC outlets quantity
24 AC outlet(s)
Power plug
IEC 60309
AC outlet types
C13 coupler, C19 coupler
I/O ports
(20) IEC 320 C13
(4) IEC 320 C19
IEC 309 32A
Input connection type
IEC 309 32A
Output connections
(20) IEC 320 C13
(4) IEC 320 C19
Features
Cable length
3050 m
Power
Nominal input voltage
230 V
Nominal output voltage
230 V
Output voltage
230 V
Load capacity
7680 VA
Maximum input current per phase
32 A
Maximum total current draw per phase
32 A
Maximum power
7680 W
Operational conditions
Operating temperature (T-T)
-25 - 65 °C
Storage temperature (T-T)
0 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Information
| Part Number: | AP7553 |
