Product Details
Weight & dimensions
Width
56 mm
Depth
51 mm
Height
1829 mm
Dimensions (WxDxH)
56 x 51 x 1829 mm
Weight
5.08 kg
Packaging data
Package width
163 mm
Package depth
117 mm
Package height
2037 mm
Package dimensions (WxDxH)
163 x 117 x 2037 mm
Package weight
8.35 kg
Logistics data
Total carbon footprint (kg of CO2e)
4728.07
Technical details
Compliance certificates
RoHS
Sustainability certificates
RoHS
Design
PDU types
Metered
Rack capacity
0U
Mounting
Vertical
Product colour
Black
Ports & interfaces
AC outlets quantity
24 AC outlet(s)
AC outlet types
C13 coupler, C19 coupler
Features
LED indicators
Y
Certification
EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Class A, ICES-003, PSE, UL Listed, VCCI Class A, VDE
Management features
Monitoring
Current, Power, Voltage
Power
Nominal input voltage
200-230 V
AC input frequency
50 - 60 Hz
Maximum current
20 A
Nominal output voltage
200-230 V
Load capacity
3680 VA
Maximum input current per phase
16 A
Maximum total current draw per phase
16 A
Maximum power
3680 W
Operational conditions
Operating temperature (T-T)
-5 - 45 °C
Storage temperature (T-T)
-25 - 65 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Non-operating altitude
0 - 15000 m
Information
| Part Number: | AP8459WW |
