APC Rack PDU 2G, Metered by Outlet with Switching, ZeroU, 20A/208V, 16A/230V, (21) C13 & (3) C19

APC Rack PDU 2G, Metered by Outlet with Switching, ZeroU, 20A/208V, 16A/230V, (21) C13 & (3) C19

£1,471.26 (incl. VAT)

Qty:

Add to basket

Part Number:	AP8659
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

APC Metered by Outlet with Switching Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and individual outlet power metering. Remote outlet level controls allow power on/off functionality for power recycling to reboot locked-up equipment and to avoid unauthorized use of individual outlets. Power sequencing delays allow users to define the order in which to power up or down attached equipment. Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding. Current metering provides real-time remote monitoring of connected loads. Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles. User-defined alarms warn of potential circuit overloads before critical IT failures occur. Users can access, configure, and control Switched rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager.

Weight & dimensions

Width 56 mm

Depth 51 mm

Height 1829 mm

Dimensions (WxDxH) 56 x 51 x 1829 mm

Weight 6.09 kg

Packaging data

Package width 162 mm

Package depth 117 mm

Package height 2038 mm

Package dimensions (WxDxH) 162 x 117 x 2038 mm

Package weight 8.36 kg

Logistics data

Total carbon footprint (kg of CO2e) 537.26

Technical details

Compliance certificates RoHS

Sustainability certificates RoHS

Design

PDU types Metered, Switched

Rack capacity 0U

Mounting Vertical

Product colour Black

Ports & interfaces

AC outlets quantity 24 AC outlet(s)

AC outlet types C13 coupler, C19 coupler

Features

Certification EN 55022 A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC 15 A, ICES-003, PSE, UL, VCCI A, VDE

Management features

Monitoring Current, Power, Voltage

Outlet control Lock-out, Recycle, Turn off, Turn on

Power

Nominal input voltage 200-230 V

AC input frequency 50 - 60 Hz

Maximum current 16 A

Nominal output voltage 200-230 V

Load capacity 3680 VA

Maximum input current per phase 16 A

Maximum total current draw per phase 16 A

Maximum power 3680 W

Operational conditions

Operating temperature (T-T) -5 - 45 °C

Storage temperature (T-T) -25 - 65 °C

Operating relative humidity (H-H) 5 - 95%

Storage relative humidity (H-H) 5 - 95%

Operating altitude 0 - 3000 m

Non-operating altitude 0 - 15000 m

Information

Part Number:

AP8659
