Product Details
Features
Product type
Network management card
Product colour
Black, Metallic
MIB support
PowerNet MIB
Easy to use
Yes
Compatibility
Easy UPS 3 Series
Certification
AS/NZS, CISPR 32, EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN/IEC 62040-2, FCC Class A, ICES-003, VCCI class A
Ports & interfaces
Interface type
RJ-45
Ethernet LAN (RJ-45) ports
1
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Network
Ethernet interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000
Security algorithms
HTTPS, SNMP, SNMPv3, SSH
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet, Fast Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000
Security algorithms
HTTPS, SNMP, SNMPv3, SSH
Web-based management
Yes
MIB support
PowerNet MIB
Management features
Web-based management
Yes
Management protocols
BACnet
Password protection
Yes
Reset button
Yes
Syslog
Yes
Power
Number of phases
3
Technical details
Total carbon footprint (kg of CO2e)
69.41
Sustainability compliance
Yes
Sustainability certificates
Federal Communications Commission (FCC), ICES, RoHS, VCCI
Total carbon footprint (kg of CO2e)
69.41
Compliance certificates
Federal Communications Commission (FCC), ICES, RoHS, VCCI
Compliance certificates
Federal Communications Commission (FCC), ICES, RoHS, VCCI
Weight & dimensions
Width
52 mm
Depth
80 mm
Height
44 mm
Weight
50 g
Package width
170 mm
Package depth
240 mm
Package height
50 mm
Package weight
300 g
Width
52 mm
Depth
80 mm
Height
44 mm
Weight
50 g
Operational conditions
Operating temperature (T-T)
-5 - 45 °C
Storage temperature (T-T)
-15 - 65 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 15240 m
Operating temperature (T-T)
-5 - 45 °C
Storage temperature (T-T)
-15 - 65 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 15240 m
Packaging content
Cables included
USB
Manual
Yes
Cables included
USB
Manual
Yes
Design
Component for
Uninterruptible power supply (UPS)
Product colour
Black, Metallic
Internal
Yes
Reset button
Yes
Certification
AS/NZS, CISPR 32, EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN/IEC 62040-2, FCC Class A, ICES-003, VCCI class A
Sustainability
Sustainability compliance
Yes
Packaging data
Package width
170 mm
Package depth
240 mm
Package height
50 mm
Package weight
300 g
Other features
Management protocols
BACnet
Interface type
RJ-45
Product type
Network management card
Compatibility
Easy UPS 3 Series
Information
| Part Number: | AP9547 |
