Product Details
Introduction
Multiple battery pack configuration
Connect up to 10 battery packs for extended runtime applications.
Advanced battery management included
Embedded monitoring at the cell, module, and cabinet level provides a clear picture of battery runtime and health, with the added benefits of predictable, consistent runtime performance, and stable cell health.
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance
Yes
Compliance certificates
RoHS, REACH, WEEE
Battery
Battery replacement accessibility
End-user
Technical details
Sustainable packaging
No
SCIP number
488c31fb-3af8-42cf-9558-1362d000a07e
Harmonized System (HS) code
85044095
Logistics data
Customs product code (TARIC)
8507208090
Total carbon footprint (kg of CO2e)
560.464173399
Country of origin
China
Features
Product colour
Black
Battery technology
Sealed Lead Acid (VRLA)
Battery voltage
192 V
Battery capacity
160 Ah
Number of batteries included
1 pc(s)
Battery life
5 year(s)
Weight & dimensions
Weight
116 kg
Width
440 mm
Height
175 mm
Depth
700 mm
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 2011.68 m
Non-operating altitude
0 - 15240 m
Information
| Part Number: | SRTG192XLBP2 |
