Product Details
Introduction
The AudioCodes C435HD IP phone is a Microsoft Teams-native entry level/common area phone designed to support the next generation of enterprise collaboration technologies. Equipped with a 4.3” color LCD screen, the C435HD supports Microsoft Teams out-of-the-box to deliver feature-rich unified communications.
AudioCodes IP phones are offered as part of a comprehensive Managed IP Phone solution, defined as an IT-managed entity that delivers end-to-end lifecycle management of edge devices.
Design
Product type
IP Phone
Handset type
Wired handset
Product colour
Black
Wall mountable
Y
Performance
Operating system installed
Android
Operating system version
9.0
Dual-Tone Multi-Frequency (DTMF) modes
SIP info
Phone features
Answering machine
Y
Call waiting
Y
Call hold
Y
Call forwarding
Y
Conference call
Y
Redialing
Y
Do not disturb function
Y
Caller ID
Y
Call park
Y
Call pick up
Y
Full duplex
Y
Call transfer
Y
Message-waiting indicator (MWI)
Y
Management features
Integrated voicemail
Y
Volume control
Buttons
Keypad number of keys
8
Display
Display
LCD
Display diagonal
10.9 cm (4.3")
Touchscreen
Y
Audio
Speakerphone
Y
Microphone mute
Y
Voice codecs
G.711, G.722, G.729, Silk
Echo cancellation
Y
Voice activity detection
Y
Adaptive jitter buffers
Y
Packet loss concealment (PLC)
Y
Network
Ethernet LAN
Y
Ethernet LAN interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Wi-Fi
N
Bluetooth
N
Supported network protocols
UDP/TCP, NTP, DNS/SRV
Quality of Service (QoS) support
Y
Security algorithms
HTTPS, SRTP, TLS
Networking standards
IEEE 802.3af
Ports & interfaces
Headset connectivity
1
Ethernet LAN (RJ-45) ports
2
DC-in jack
Y
Cable lock slot
Y
Power
Power over Ethernet (PoE)
Y
AC adapter input voltage
100 - 240 V
Input current
2 A
AC adapter output voltage
12 V
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Weight & dimensions
Width
249 mm
Depth
132 mm
Weight
960 g
Height (min)
16.1 cm
Height (max)
18.9 cm
Package width
316 mm
Package depth
255 mm
Package height
95 mm
Package weight
1.39 kg
Packaging content
Number of handles included
1 pc(s)
Manual
Y
Cables included
LAN (RJ-45)
Information
| Part Number: | TEAMS-C435HD-R |
