Product Details
Packaging data
Quantity per pack
1 pc(s)
Indoor unit included
Yes
Outdoor unit included
No
Technical details
Connectivity technology
Wired
Colour
Yes
Speakerphone
Yes
Streaming capability
Yes
Echo cancellation
Yes
Wall mountable
Yes
Built-in microphone
Yes
Warranty period
5 year(s)
Certification
CSA, UL/cUL, CE, VCCI, RCM
Display
Display diagonal
17.8 cm (7")
Display technology
LCD
Display resolution
1024 x 600 pixels
Touchscreen
Yes
Touchscreen type
Capacitive
Video formats supported
H.264, MPEG4
Audio
Built-in speaker(s)
Yes
Voice codecs
G.711, G.722, G.729
Design
Product colour
White
Housing material
Plastic
Network
Ethernet interface type
Fast Ethernet
Ethernet LAN data rates
10,100 Mbit/s
Ethernet LAN (RJ-45) ports
1
Cabling technology
10/100Base-T(X)
Power over Ethernet (PoE)
Yes
Supported network protocols
IPv4, HTTP, HTTPS1, SIP 2.0, SIPS, SSL/TLS1, RTP, SRTP, RTSP, DHCP, NTP, TCP, IGMP, UDP, DNS, Syslog, FTP, SMTP, RTCP, ICMP, DHCPv4
Security algorithms
EAP-TLS, HTTPS, MSCHAPv2, PEAP, TLS
Power
Indoor unit power type
DC/PoE
Power consumption (typical)
2.9 W
Power consumption (standby)
12 W
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
193 mm
Height
157 mm
Weight
555 g
Logistics data
Quantity per pack
1 pc(s)
Information
| Part Number: | 03238-001 |
