Introduction
Ex Connection Rail 4-port PoE PS24
Ex Connection Rail 4-port PoE PS24 is a high-performance PoE switch and 24 V DC power supply for hazardous areas. It is designed to connect explosion-protected network cameras in the ExCam series over long distances. The network connection can be realized via optical fibers or copper-bound Ethernet. The power supply can deliver 30 W per camera when additional heat is needed in sub-zero environments. The Ex d-rated enclosure is made from seawater resistant copper free aluminum and ready for wall mounting. Ex Connection Rail includes 2x M25x1.5 cable glands (Ex d).
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
4
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Network
Networking standards
IEEE 802.3at
10G support
N
Copper ethernet cabling technology
10BASE-T,100BASE-FX,100BASE-TX
Design
Product colour
Aluminium
Housing material
Aluminium
Certification
ATEX, IECEx, EAC
Power
AC input voltage
100 - 240 V
Output voltage
24 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Y
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
120 W
Operational conditions
Operating temperature (T-T)
-60 - 50 °C
Storage temperature (T-T)
-60 - 50 °C
Operating relative humidity (H-H)
10 - 100%
Weight & dimensions
Width
289 mm
Depth
289 mm
Height
227 mm
Weight
16 kg
Information
| Part Number: | 01535-001 |
