Product Details
Performance
Video input channels
64 channels
Operating system installed
Windows 10 IoT Enterprise
Storage
Number of HDDs installed
8
HDD capacity
8000 GB
Number of HDDs supported
12
Total installed storage capacity
64000 GB
Maximum storage capacity
96 TB
RAID support
Y
RAID levels
0,1,5,6,10
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
VGA (D-Sub) output ports
2
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Features
Rack mounting
Y
Rack capacity
2U
Product colour
Black, Grey
Certification
EN/IEC/UL 60950-1, FCC part 15 class A, VCCI class A, RCM AS/NZS CISPR 32 Class A, EN 55032, class A, ICES-003/NMB-003 Class A, KC KN32 Class A, KN-35, EN 55024, EN/IEC 61000-3-2, EN/IEC 61000-3-3, NOM, BSMI, EAC
Processor
Built-in processor
Y
Power
Power consumption (max)
750 W
AC input voltage
100-240 V
AC input frequency
50 - 60 Hz
Output current
5 A
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Operating relative humidity (H-H)
20 - 80%
Storage temperature (T-T)
-40 - 65 °C
Weight & dimensions
Width
482 mm
Depth
681 mm
Height
87 mm
Weight
22.3 kg
Packaging content
Cables included
AC
Information
| Part Number: | 01615-001 |
