Product Details
Performance
Channels quantity
4 channels
Alarm input channels
4
Alarm output channels
4
Maximum video resolution
3840 x 2160 pixels
Maximum frame rate
30 fps
Built-in processor
Yes
Internal memory
2048 MB
Live view
Yes
Video formats supported
H.264, H.265
Audio formats supported
AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
Languages support
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Features
Placement supported
Indoor
Brand compatibility
Axis
Compatibility
F2105-RE
F2115-R
F2135-RE
F4105-LRE
F7225-RE
Product colour
Green, Grey
Video compression formats
H.264, H.265, M-JPEG
Wide Dynamic Range (WDR)
Y
Memory card slot
Y
Certification
UL
Product colour
Green, Grey
On/off switch
Yes
LED indicators
Status
Certification
Safety: UL recognized component, IS 13252; Network: NIST SP500-267; Cybersecurity: ETSI EN 303 645, BSI IT Security Label, FIPS-140
Image sensor
Resolution
1920 x 1080 pixels
Storage
Internal storage capacity
0.5 GB
Storage media type
Flash
Network
Ethernet LAN data rates
10,100,1000 Mbit/s
Cabling technology
10/100/1000BaseE-T(X)
Networking standards
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3at
Supported network protocols
IPv4, IPv6 (USGv6), ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS (DiffServ), FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3, DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, RTCP, DHCP, SSH, SIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Management features
Web-based management
Yes
Syslog
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Audio connector type
3.5 mm (1/8")
RS-232 ports
1
RS-485 ports
1
DC-in jack
Yes
Connectivity technology
Wired
Power
Power over Ethernet (PoE)
Yes
Power consumption (min)
9 W
Power consumption (max)
25.5 W
Input voltage
10 - 48 V
Power consumption (typical)
11 W
Operational conditions
Operating temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
10 - 85%
Storage temperature (T-T)
-40 - 65 °C
Storage relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-40 - 60 °C
System requirements
Browser supported
Chrome, Firefox, Edge, Safari
Packaging data
Quantity per pack
1 pc(s)
Weight & dimensions
Width
123 mm
Depth
160 mm
Height
43 mm
Weight
190 g
Logistics data
Quantity per pack
1 pc(s)
Packaging content
Manual
Yes
Technical details
Doesn't contain
PVC
Warranty period
5 year(s)
Information
| Part Number: | 01991-031 |
