Product Details
Performance
Type
IP security camera
Placement supported
Outdoor
Connectivity technology
Wired
Wide Dynamic Range (WDR)
Y
Day/night mode
Y
Languages support
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian
Number of languages
11
Infrared (IR) cut-off filter
Y
Certification
EAC, EN 55032 A, EN 55035, EN 50121-4,
IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-3(A)/NMB-3(A), VCCI A, RCM AS/NZS CISPR 32 A, KC KN32 A, KC KN35, CISPR 24, CISPR 35
IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, CAN/CSA-C22.2 No. 60950-22, IS 13252
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6,
IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78,
IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10, NEMA 250 4X, NEMA TS 2 (2.2.7-2.2.9), MIL-STD-810H (Method 501.7, 502.7, 505.7, 506.6, 507.6, 509.7, 512.6)
NIST SP500-267
Design
Mounting type
Ceiling/wall
Product colour
White
Housing material
Aluminium, Polycarbonate (PC)
International Protection (IP) code
IP66, IP67
IK code
IK10
Camera
Camera pan control
Y
Camera tilt control
Y
Minimum illumination
0.05 lx
Viewing angle, horizontal
180°
Viewing angle, vertical
90°
Tilt angle range
0 - 50°
Pan range
-180 - 180°
Camera shutter speed
1/91000 - 1/25, 1/50000 - 1/25 s
Image sensor
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Progressive scan
Y
Sensor type
CMOS
Lens system
Maximum aperture number
2
Fixed focal length
3.2 mm
Video
Maximum resolution
5120 x 2560 pixels
Total megapixels
13 MP
Video compression formats
AVC,H.264,H.265,HEVC,M-JPEG,MPEG4
Frame rate
30 fps
Video streaming
Y
Noise reduction
Y
Image quality adjustment
Brightness, Contrast, Saturation, Sharpness
Audio
Audio system
2-way
Voice codecs
G.711,G.726,OPUS
Network
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
Networking standards
IEEE 802.1x,IEEE 802.3at
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPS , TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, CDP, MQTT, Syslog, Link-Local address (ZeroConf)
Wi-Fi
N
Bluetooth
N
Quality of Service (QoS) support
Y
Storage
Built-in HDD
N
Card reader integrated
Y
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
512 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Microphone in
Y
Security
Password protection
Y
IP address filtering
Y
Security algorithms
EAP-TLS,FIPS 140-2
HTTPS encryption
Y
Management features
Web-based management
Y
Power
Power source type
PoE
Power consumption (typical)
11 W
Power consumption (max)
18 W
Operational conditions
Operating temperature (T-T)
-40 - 50 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
206 mm
Height
221 mm
Weight
2.2 kg
Packaging content
Number of cameras
1
Information
| Part Number: | 02060-001 |
