Introduction
Ideal for improving operational efficiency, this halogen-free, thermometric camera lets you remotely monitor temperatures and trigger temperature-based events. Robust and impact-resistant, it offers early fire detection analytics and built-in cybersecurity features.
What’s the temperature?
AXIS Q1961-TE lets you remotely monitor temperatures from -40 °C to 350 °C (-40 °F to 660 °F)*. So, you don’t need to be onsite to know if your equipment is getting close to overheating - you’ll receive a notification if the temperature passes a set threshold, or if it increases or decreases too rapidly. This allows you time to act to avoid unwanted downtime and it enables predictive maintenance planning. AXIS Q1961-TE supports up to 10 configurable polygonal detection areas, making it possible to monitor areas for specific temperature levels. With spot temperature reading, you can click on the image and see the exact temperature in the specific area. Furthermore, through metadata, you’ll have access to temperature statistics.
Detect early signs of fire
In addition to offering powerful analytics capabilities, AXIS Q1961-TE comes with early fire detection preinstalled making it possible to set triggers and get warnings about early signs of fire or potential overheating. With smart filtering, it can disregard uninteresting hot objects such as the warm exhausts of passing work vehicles, so you’ll receive fewer false notifications.
Depend on it - robust and secure
Ideal for installation in harsh environments, this robust temperature measuring camera is highly resistant to corrosion. It offers great reliability and includes built-in cybersecurity features to help prevent unauthorized access and safeguard your system. For instance, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis products on your network. Plus, it includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified. Electronic image stabilization (EIS) provides smooth video even in scenes with vibrations. Furthermore, thanks to edge-to-edge technology it’s possible to connect a network speaker to enable audio alarms.
Performance
Type
IP security camera
Placement supported
Outdoor
Connectivity technology
Wired
Thermal module
Y
Processor model
ARTPEC-8
Built-in processor
Y
Number of languages
19
Languages support
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Thermal sensitivity (NETD)
40 mK
Certification
CSA, UL/cUL, UKCA, CE, KC
Design
Form factor
Bullet
Mounting type
Wall
Product colour
White
Housing material
Aluminium, Polycarbonate (PC)
International Protection (IP) code
IP66, IP67
IK code
IK10
Camera
Lens viewing angle, horizontal
55°
Camera pixel size
17 µm
Image sensor
Sensor type (thermal module)
Noise equivalent temperature difference (NETD)
Sensor type
Microbolometer
Lens system
Lens diameter
7 mm
Maximum aperture number
1.18
Night vision
Video
Maximum resolution
384 x 288 pixels
Video compression formats
H.264, H.265, M-JPEG
Video recording
Y
Frame rate
30 fps
Video streaming
Y
Gain control type
Auto
Privacy masking
Y
Audio
Audio system
1-way
Audio input channels
1
Audio output channels
1 channels
Network
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
Networking standards
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Wi-Fi
N
Bluetooth
N
Quality of Service (QoS) support
Y
Storage
Built-in HDD
N
Card reader integrated
Y
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
8192 MB
Internal memory
2048 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Headphone outputs
1
Terminal block port
Y
DC-in jack
Y
Security
Temperature sensor
Y
Temperature measurement range
-40 - 350 °C
Temperature measurement accuracy
5 °C
Fire detection
Y
Password protection
Y
Video motion detection
Y
Active tampering alarm
Y
IP address filtering
Y
Mirror
Y
Pixel counter
Y
Digest authentication
Y
Network access storage (NAS)
Y
Power
Power source type
DC, PoE
Power consumption (typical)
4.1 W
Power consumption (max)
12.95 W
Power consumption (Power over Ethernet (PoE))
4.3 W
DC output voltage
10, 12, 15, 16, 24, 28
Operational conditions
Operating temperature (T-T)
-40 - 60 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Diameter
13.2 cm
Length
272 mm
Weight
1.4 kg
Packaging content
Number of cameras
1
Manual
Y
Packaging content
Drill template, TORX L-keys, terminal block connectors, connector guard, cable gaskets, owner authentication key
