Introduction
This dual-sensor, multidirectional camera delivers excellent image quality even in challenging light conditions. Built on ARTPEC-8, it offers support for advanced analytics based on deep learning on the edge.
See it all - 24/7
AXIS P4705-PLVE includes 360° IR illumination with individually controllable LEDs so you’ll enjoy clear images even in low light or complete darkness as well as undistorted colors during the day. Featuring AXIS Lightfinder you get color images recorded in near darkness. And Forensic WDR ensures clarity when there’s both dark and light areas in the scene. It offers two 2 MP channels and a frame rate of 30 fps letting you capture both wide angle and zoomed-in, detailed views. And, thanks to 2.5x zoom it delivers wide views and you can zoom in for all the details. Furthermore, audio input allows you to listen in to transactions or incidents.
Brilliant design
This compact, multidirectional camera is perfect when you need to see in two directions simultaneously. It offers flexible positioning of both varifocal camera heads and each head can be controlled individually so you can monitor scenes in two directions in wide or zoomed-in views. The camera’s sensors can also be twisted, allowing two camera heads to be positioned closer together. This is the perfect setup for straight hallways or at the corners of an intersection where it can look in both directions simultaneously.
Deep learning on the edge
Built on ARTPEC-8, this high-performance camera includes a deep learning processing unit (DLPU). This enables improved processing and storage capabilities allowing you to collect and analyze even more data than before—on the edge. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, AXIS P4707-PLVE can detect and classify humans, vehicles, and types of vehicles—all tailored to your specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge.
Cost-efficient installation
With two camera heads in one camera, AXIS P4707-PLVE offers cost-effective installation. That’s because there’s only one camera to install, one cable to draw, one IP address, one video management software (VMS) license, and just one license for any analytics you choose to install. Including an optional IP66/IP67 rated weather shield, this high performance camera is ideal for outdoor wall mounting. It offers edge storage for added storage capability and reliability. And, thanks to remote zoom and focus capabilities it eliminates the need for hands-on fine tuning and ensures fast and accurate installation. Furthermore, Zipstream with H.264/ H.265 significantly lowers bandwidth and storage requirements.
Performance
Type
IP security camera
Placement supported
Indoor & outdoor
Connectivity technology
Wired
Wide Dynamic Range (WDR)
Y
Day/night mode
Y
Type
IP security camera
Placement supported
Outdoor
Connectivity technology
Wired
PTZ control
Yes
Auto-tracking
Yes
Tour recording
Yes
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Infrared (IR) cut-off filter
Yes
Processor model
ARTPEC-7
Built-in processor
Yes
Number of languages
19
Languages support
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Certification
EN 55032 Class A, EN 55035, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, KS C 9832 Class A, KS C 9835
Design
Form factor
Bulb
Mounting type
Ceiling/wall
Product colour
Black, White
International Protection (IP) code
IP66, IP67
IK code
IK10
Mounting type
Wall
Product colour
White
Housing material
Aluminium, Polycarbonate (PC)
International Protection (IP) code
IP66, IP67
IK code
IK10
Camera
Angle of rotation
170°
Lens viewing angle, horizontal
107 - 39°
Lens viewing angle, vertical
55 - 22°
Lens viewing angle, diagonal
131 - 45°
Tilt angle range
-75 - 75°
Pan range
-100 - 110°
Camera shutter speed
1/20000 - 1.5 s
Camera pan control
Yes
Camera tilt control
Yes
Minimum illumination
0.11 lx
Lens viewing angle, horizontal
58.5°
Lens viewing angle, vertical
34.9°
Tilt angle range
-90 - 20°
Tilt speed
500 °/sec
Pan speed
550 °/sec
Camera shutter speed
1/8500 - 1/5 s
Panoramic camera
Sensor type (panoramic camera)
CMOS
Optical sensor size (panoramic camera)
25.4 / 2.8 mm (1 / 2.8")
Camera shutter speed (panoramic camera)
1/20000 - 1.5 s
Minimum illumination (panoramic camera)
0.1 lx
Image sensor
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Sensor type
CMOS
Optical sensor size
25.4 / 2 mm (1 / 2")
Progressive scan
Yes
Sensor type
CMOS
Lens system
Zoom capability
Y
Number of lenses
1
Auto focus
Y
Focal length range
3.3 – 8.1
Zoom capability
Yes
Optical zoom
31x
Digital zoom
12x
Focal length range
6.91 - 214.64 mm
Auto focus
Yes
Maximum aperture number
4.6
Minimum aperture number
1.36
Night vision
Night vision
Y
LED type
IR
Night vision
Yes
Night vision distance
200 m
LED type
IR
Infra-red wavelength
850 nm
Video
Maximum resolution
1920 x 1080 pixels
Total megapixels
2 MP
Video compression formats
H.264, H.265, M-JPEG
Supported graphics resolutions
640 x 360, 1920 x 1080 (HD 1080)
Supported video modes
1080p
Frame rate
60 fps
Video streaming
Y
Image quality adjustment
Brightness, Contrast, Sharpness
Maximum resolution
3840 x 2160 pixels
Video compression formats
H.264, H.265, M-JPEG
Video recording
Yes
Frame rate
25 fps
Video streaming
Yes
Privacy masking
Yes
Audio
Built-in speaker(s)
Y
Audio system
2-way
Audio codecs
24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz
Network
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
Networking standards
IEEE 802.1x, IEEE 802.3at
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf)
Wi-Fi
N
Bluetooth
N
Quality of Service (QoS) support
Y
Live view
Y
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Networking standards
IEEE 802.1x, IEEE 802.3bt
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Wi-Fi
No
Bluetooth
No
Quality of Service (QoS) support
Yes
Storage
Built-in HDD
N
Card reader integrated
Y
Built-in HDD
No
Card reader integrated
Yes
Compatible memory cards
SD, SDHC, SDXC
Flash memory
512 MB
Internal memory
2048 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Ethernet LAN (RJ-45) ports
1
Security
Password protection
Y
IP address filtering
Y
Security algorithms
HTTPS
Password protection
Yes
Video motion detection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Digest authentication
Yes
Network access storage (NAS)
Yes
Power
Power source type
PoE
Power consumption (Power over Ethernet (PoE))
7.9 W
Power source type
PoE
AC input voltage
100 - 240 V
Power consumption (typical)
17 W
Power consumption (max)
51 W
Operational conditions
Operating temperature (T-T)
-30 - 50 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-50 - 50 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
133 mm
Depth
208 mm
Height
88 mm
Weight
975 g
Height
261 mm
Diameter
23.9 cm
Weight
4.8 kg
Packaging content
Number of cameras
2
Number of cameras
1
Manual
Yes
Packaging content
Windows decoder 1-user license, 60 W Midspan (including power cable), IP66 rated network connector, repaint template, paint paper
Technical details
