Introduction
This discreet dome delivers great images in any light conditions. With a deep learning processing unit, it offers intelligent analytics based on deep learning on the edge. Plus, Axis Edge Vault safeguards your device.
Great images, every time
Ideal for indoor surveillance applications, AXIS M4218-LV delivers great image quality in superior 4K. With a varifocal lens, this affordable camera offers a flexible field of view. Plus, with remote zoom and auto focus capabilities, it ensures sharp high resolution video with great details where needed. Thanks to WDR, it can handle difficult light conditions. And Axis OptimizedIR allows for surveillance in pitch darkness. Furthermore, Axis Edge Vault provides a hardware-based cybersecurity platform that guarantees the device’s integrity and protects it from unauthorized access.
Extended possibilities
AXIS M4218-LV offers great possibilities to add value to your camera and extend the functionality of your surveillance system. For instance, with an HDMI port and AXIS Face Detector you can display live video and face detection on a public viewing monitor to help deter theft. Plus, you can add audio or I/O connectivity using AXIS T61 Series. It offers advanced analytics based on deep learning on the edge to deliver valuable metadata facilitating efficient forensic search capabilities in live or recorded video. And AXIS Object Analytics including time in area feature lets you track whenever an object stays in a defined area longer than a user-defined time, for example, to detect loitering.
Small and discreet
Compact and flexible in design, this varifocal dome offers flexible and discreet installation. With a wide range of accessories, it can be installed almost anywhere making it ideal for any location where discreet monitoring is needed. And it can be easily repainted to blend in seamlessly with any environment. This IK08-rated camera is protected against redirection, defocusing, and impact. A smoked dome is available as an accessory to disguise which way the camera is pointing. Furthermore, thanks to its vandal-, impact-, and dust-resistant casing you can be confident it’s always safe and secure.
Performance
Type
IP security camera
Placement supported
Indoor
Connectivity technology
Wired
PTZ control
Y
PTZ modes
Digital PTZ
Wide Dynamic Range (WDR)
Y
Day/night mode
Y
Built-in processor
Y
Infrared (IR) cut-off filter
Y
Number of languages
19
Languages support
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Certification
CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM
Design
Form factor
Dome
Mounting type
Ceiling/wall
Product colour
White
Housing material
Aluminium, Polycarbonate (PC)
International Protection (IP) code
IP42
IK code
IK08
Camera
Camera pan control
Y
Camera tilt control
Y
Minimum illumination
0.24 lx
Angle of rotation
105°
Lens viewing angle, horizontal
93 - 47°
Lens viewing angle, vertical
50 - 26°
Tilt angle range
-40 - 65°
Pan range
-180 - 180°
Camera shutter speed
1/71500 - 1/5 s
Image sensor
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Progressive scan
Y
Sensor type
CMOS
Lens system
Zoom capability
Y
Maximum aperture number
2.6
Minimum aperture number
1.7
Night vision
Video
Maximum resolution
3840 x 2160 pixels
Total megapixels
8 MP
Video compression formats
H.264, H.265, M-JPEG
Video recording
Y
Frame rate
15 fps
Video streaming
Y
Noise reduction
Y
Noise reduction technology
2D noise reduction, 3D noise reduction
Privacy masking
Y
Network
Ethernet LAN
Y
Ethernet interface type
Fast Ethernet
Networking standards
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Link-Local address (ZeroConf)
Wi-Fi
N
Bluetooth
N
Quality of Service (QoS) support
Y
Storage
Built-in HDD
N
Card reader integrated
Y
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
512 MB
Internal memory
2048 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
HDMI ports quantity
1
Security
Password protection
Y
Video motion detection
Y
Active tampering alarm
Y
IP address filtering
Y
Mirror
Y
Pixel counter
Y
Digest authentication
Y
Network access storage (NAS)
Y
Power
Power source type
PoE
Power consumption (max)
9.7 W
Power consumption (Power over Ethernet (PoE))
5 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-30 - 65 °C
Operating relative humidity (H-H)
10 - 85%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Height
71 mm
Diameter
12 cm
Weight
375 g
Packaging content
Number of cameras
1
Manual
Y
Packaging content
Owner authentication key, virtual client license for H.264/H.265
