Introduction
This box camera delivers excellent 5 MP image quality. Ideal for various surveillance situations, it offers an exchangeable lens so you can change the lens to suit your needs. Plus, it’s designed for use outdoors in housing.
A camera you can count on
With electronic image stabilization, AXIS P1387 ensures stable images despite vibration. Scene profiles can be automatically optimized to suit specific scenarios. And thanks to shock detection and a tampering alarm, you’ll be informed if there’s any attempts to interfere with the camera. Barrel distortion correction delivers great image quality, even at the edges of the image. Plus, corridor format ensures the video is perfectly adapted to monitored corridors or tunnels. With support for PoE and redundant DC power, this box camera offers flexible installation. Furthermore, it’s designed to fit into outdoor housing.
More light or less
With an exchangeable lens and i-CS support, you can easily change the lens, making this camera ideal for various surveillance situations. Use our lens calculator to select a lens that meets your specific needs. This box camera offers excellent image quality in 5 MP. With Lightfinder 2.0, and Forensic WDR it delivers true colors and great detail in challenging light or near darkness. In addition, P-Iris ensures images with better contrast, clarity, resolution, and depth of field.
Secure and powerful
AXIS P1387 offers Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. Built on an Axis system-on-chip, it includes a deep learning processing unit (DLPU) so you can run advanced features and powerful analytics on the edge. For instance, AXIS Object Analytics can detect and classify different types of objects. This DLPU also ensures improved processing and storage capabilities so you can collect and analyze even more data than before. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video.
Performance
Type
IP security camera
Placement supported
Indoor
Connectivity technology
Wired
PTZ control
Yes
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Infrared (IR) cut-off filter
Yes
Processor model
ARTPEC-8
Built-in processor
Yes
Languages support
Multi
Dynamic range
120 dB
Design
Form factor
Box
Mounting type
Wall
Product colour
White
Housing material
Aluminium
Camera
Minimum illumination
0.008 lx
Lens viewing angle, horizontal
24 - 112°
Lens viewing angle, vertical
18 - 80°
Camera pixel size
2 µm
Camera shutter speed
1/66500 - 2 s
Image sensor
Optical sensor size
25.4 / 2.7 mm (1 / 2.7")
Sensor type
CMOS
Lens system
Number of lenses
1
Focal length range
2.8 - 13 mm
Auto focus
Yes
Minimum aperture number
1.4
Detect distance (wide)
56.2 m
Detect distance (tele)
244.2 m
Observe distance (wide)
22.3 m
Observe distance (tele)
96.9 m
Recognize distance (wide)
11.2 m
Recognize distance (tele)
48.8 m
Identify distance (wide)
5.6 m
Identify distance (tele)
24.4 m
Video
Maximum resolution
2592 x 1944 pixels
Total megapixels
5 MP
Video compression formats
H.264, H.265, M-JPEG, MPEG4
Supported graphics resolutions
160 x 120, 160 x 90, 2592 x 1944
Frame rate
60 fps
Video streaming
Yes
Noise reduction
Yes
Noise reduction technology
2D noise reduction, 3D noise reduction
Gain control type
Auto
Image quality adjustment
Brightness, Contrast, Sharpness
Flip & mirror
Yes
Privacy masking
Yes
Image stabilizer
Yes
Bit rate control
Variable Bit Rate (VBR)
Audio
Audio system
2-way
Audio formats supported
G.711, G.726, LPCM, OPUS
Signal-to-Noise Ratio (SNR)
55 dB
Built-in microphone
Yes
Audio detection
Yes
Network
Ethernet LAN
Yes
Ethernet interface type
Fast Ethernet, Gigabit Ethernet
Networking standards
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Wi-Fi
No
Bluetooth
No
Quality of Service (QoS) support
Yes
Streaming method
Multicast
Storage
Built-in HDD
No
Card reader integrated
Yes
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
8192 MB
Internal memory
2048 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
RS-422 ports
1
RS-485 ports
1
Microphone in
Yes
Terminal block port
Yes
DC-in jack
Yes
Security
Alarm input channels
2
Alarm output channels
2
Video motion detection
Yes
Active tampering alarm
Yes
Intelligent Video Surveillance (IVS) system features
Face detection, Human detection, Line crossing detection, Scene change, Vehicle detection
Power
Power source type
DC, PoE
Power consumption (typical)
4.26 W
Power consumption (max)
10.57 W
Power consumption (Power over Ethernet (PoE))
11.73 W
DC output voltage
10, 28
Operational conditions
Operating temperature (T-T)
-10 - 55 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 85%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
80 mm
Depth
225 mm
Height
63.5 mm
Weight
480 g
Weight (with stand)
775 g
Sustainability
Compliance certificates
CE, EAC, KC, RCM, REACH, RoHS, UKCA, UL, VCCI, cUL
Packaging content
Number of cameras
1
Mounting kit
Yes
Manual
Yes
Terminal block included
Yes
