Introduction
Ideal for long distance surveillance, this all-in-one, outdoor-ready bullet camera delivers superior image quality in 41 MP with high light sensitivity and extremely high pixel density.
See all the details
Built on a dual Axis system-on-chip, this device delivers extreme detail over great distances and excellent forensic value. It offers 41 MP at 15 fps or 8K at up to 30 fps. And a 4/3” image sensor ensures exceptional low-light performance. With a custom-made, tele Canon lens, it’s perfect for long-distance surveillance and delivers extremely high pixel density. Electronic image stabilization (EIS) ensures smooth video in situations where a camera is subject to vibrations, for instance, at sports arenas or windy harbors. Furthermore, Axis Zipstream reduces bandwidth and storage requirements without compromising image quality.
All-in-one and ready for everything
This powerful camera offers everything you need and is out-of-the-box ready to use. Enclosed in a robust aluminum casing, it also includes a mounting arm for easy installation. And a spacious back box ensures secure cable management. It features a custom-made, tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view. With 3x zoom, it’s ideal for identification purposes. In addition, thanks to PoE out, you can connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation.
Secure and robust surveillance
AXIS Q1809-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. This robust, weather-protected, outdoor-ready camera is IP66-, IP67-, IK10- and NEMA 4X-rated and features a IK08-rated impact-resistant glass front window. It has an operating temperature range from -40 °C to 55 °C (-40 °F to 131 °F). Furthermore, surge protection minimizes damage in the case of a power surge.
Performance
Type
IP security camera
Placement supported
Outdoor
Connectivity technology
Wired
PTZ control
Yes
PTZ modes
Digital PTZ
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Infrared (IR) cut-off filter
Yes
Certification
CSA, UL/cUL, CE, EAC, VCCI, RCM
Design
Form factor
Bullet
Mounting type
Ceiling/wall
Product colour
Black, White
Housing material
Aluminium, Glass
Protection features
Impact resistant
International Protection (IP) code
IP66, IP67
IK code
IK10
Camera
Minimum illumination
0.04 lx
Angle of rotation
270°
Lens viewing angle, horizontal
21 - 7°
Lens viewing angle, vertical
12 - 4°
Tilt angle range
0 - 90°
Pan range
-180 - 180°
Camera pixel size
2.315 µm
Camera shutter speed
1/15500 - 2 s
Image sensor
Number of sensors
1
Optical sensor size
101.6 / 3 mm (4 / 3")
Sensor type
CMOS
Lens system
Zoom capability
Yes
Number of lenses
1
Focal length range
50 - 150 mm
Focus
Motorized
Maximum aperture number
4
Detect distance (wide)
853.8 m
Detect distance (tele)
2551.6 m
Observe distance (wide)
338.8 m
Observe distance (tele)
1012.6 m
Recognize distance (wide)
170.8 m
Recognize distance (tele)
510.2 m
Identify distance (wide)
85.4 m
Identify distance (tele)
255.2 m
Closest focusing distance
5 m
Night vision
Night vision
Yes
LED type
IR
Infra-red wavelength
900 nm
Video
Maximum resolution
7680 x 4320 pixels
Total megapixels
41 MP
Video formats supported
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Video compression formats
H.264, H.265
Supported graphics resolutions
160 x 120, 160 x 90, 1280 x 800, 3840 x 2160
Frame rate
30 fps
Video streaming
Yes
Noise reduction
Yes
Noise reduction technology
2D noise reduction, 3D noise reduction
Gain control type
Auto
Image quality adjustment
Brightness, Contrast, Mirror, Sharpness
Text caption overlay
Yes
Image stabilizer
Yes
Bit rate control
Variable Bit Rate (VBR)
Audio
Audio formats supported
AAC-LC, ADPCM, G.711, G.726, LPCM, PCM
Sample rate
48 kHz
Signal-to-Noise Ratio (SNR)
55 dB
Network
Ethernet LAN
Yes
Networking standards
IEEE 802.1AE, IEEE 802.1x
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSd , HTTP/2, TLSd , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Wi-Fi
No
Bluetooth
No
Quality of Service (QoS) support
Yes
Streaming method
Multicast
Storage
Built-in HDD
No
Card reader integrated
Yes
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
8192 MB
ROM capacity
4096 MB
Ports & interfaces
Microphone in
Yes
Terminal block port
Yes
DC-in jack
Yes
Security
Password protection
Yes
Security algorithms
EAP-TLS, HTTPS
Alert notification type
E-mail
Pixel counter
Yes
Digest authentication
Yes
Management features
Cloud-managed
Yes
Remotely operated
Yes
Power
Power source type
DC, PoE
Power consumption (typical)
17.6 W
Power consumption (max)
35 W
Power consumption (Power over Ethernet (PoE))
18.9 W
Operational conditions
Operating temperature (T-T)
-40 - 55 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Depth
411 mm
Height
183 mm
Diameter
18.3 cm
Weight
3.2 kg
Sustainability
Compliance certificates
REACH, RoHS
