Introduction
This purpose-tuned camera is ideal for traffic surveillance and smart city initiatives - enabling you to capture sharp license plate images 24/7. Made for 3rd party LPR software, it can help law enforcement agencies improve road safety and gather valuable intelligence.
Extraordinary accuracy 24/7
Designed to capture license plates with exceptional clarity and sharpness, this purpose-tuned camera comes preconfigured with advanced algorithms focusing solely on license plates. This ensures the required pixel density for accurate identification - with practically no setup required! It can capture plates at speeds up to 250 km/h (155 mph) in single lanes and from distances of up to 100 m (328 ft) during daylight. In pitch darkness, the camera captures license plate images at up to 50 m (164 ft), and up to 100 m (328 ft) with the optional accessory AXIS T90D20 IR-LED Illuminator delivering unmatched, reliable performance day and night.
Do it your way
AXIS Q1800-LE is fully compatible with edge- or server-based LPR software from any leading third-party vendor, giving you the freedom to choose the license plate recognition analytics that best suit your needs. Built on the Axis open platform, it integrates seamlessly with most third-party video management software (VMS) and supports a wide range of third-party applications and analytics. Plus, with various installation accessories available, this camera offers flexible mounting options, making it an ideal solution for any deployment.
Ready for anything
This purpose-tuned camera ensures accurate license plate capture 24/7 with minimal setup. Robust and weatherproof, it ensures durability in the toughest conditions. It includes an extra-long weathershield that can withstand hurricane-force winds of up to 60 m/s (134 mph) and resist harsh weather impacts (IK10-rated casing, IK08-rated front glass, and IP66- and NEMA 4X-rated). Plus, electronic image stabilization ensures stable images in situations where the camera is subject to vibrations. What’s more, the discreet gray color housing and black weathershield blend right into any traffic environment.
Performance
Type
IP security camera
Placement supported
Outdoor
Connectivity technology
Wired
PTZ control
Yes
PTZ modes
Digital PTZ
Preset points
Yes
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Infrared (IR) cut-off filter
Yes
Certification
UL/cUL, BIS, UKCA, CE, KC, VCCI, RCM
Design
Form factor
Bullet
Mounting type
Wall
Product colour
Black
Housing material
Aluminium, Glass
Protection features
Impact resistant, Vandal proof, Weather resistant
International Protection (IP) code
IP66
IK code
IK08, IK10
Camera
Minimum illumination
0.06 lx
Angle of rotation
270°
Horizontal field of view (thermal module)
38 - 2.3°
Lens viewing angle, horizontal
22 - 1.3°
Tilt angle range
0 - 90°
Pan range
-180 - 180°
Camera pixel size
2.9 µm
Camera shutter speed
1/111000 - 2 s
Image sensor
Number of sensors
1
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Sensor type
CMOS
Panoramic camera
Sensor type (panoramic camera)
CMOS
Signal-to-Noise Ratio (SNR) (panoramic camera)
55 dB
Lens system
Number of lenses
1
Focal length range
7 - 138 mm
Auto focus
Yes
Identify distance
1.2 m
Detect distance (wide)
96.7 m
Detect distance (tele)
1884.2 m
Observe distance (wide)
38.4 m
Observe distance (tele)
747.7 m
Recognize distance (wide)
19.3 m
Recognize distance (tele)
376.8 m
Identify distance (wide)
9.7 m
Identify distance (tele)
188.4 m
Closest focusing distance
1.2 m
Night vision
Night vision
Yes
Night vision distance
100 m
B/W night vision distance
50 m
LED type
IR
Infra-red wavelength
850 nm
Video
Maximum resolution
1920 x 1080 pixels
Video formats supported
AVC, H.264, H.265, M-JPEG
Supported graphics resolutions
160 x 120, 320 x 180, 1400 x 1050 (SXGA+), 1920 x 1080 (HD 1080)
Supported video modes
1080p
Frame rate
90 fps
Video streaming
Yes
Noise reduction
Yes
Noise reduction technology
2D noise reduction, 3D noise reduction
Image quality adjustment
Brightness, Contrast, Saturation, Sharpness
Text caption overlay
Yes
Image stabilizer
Yes
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Audio
Built-in speaker(s)
Yes
Audio system
2-way
Audio formats supported
AAC-LC, ADPCM, LPCM, OPUS, PCM
Sample rate
48 kHz
Signal-to-Noise Ratio (SNR)
55 dB
Audio detection
Yes
Network
Ethernet LAN
Yes
Networking standards
IEEE 802.3af, IEEE 802.3at
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS3 , HTTP/ 2, TLS3 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Streaming method
Multicast
Storage
Card reader integrated
Yes
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
8192 MB
Internal memory
2048 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Microphone in
Yes
Terminal block port
Yes
DC-in jack
Yes
Security
Password protection
Yes
Video motion detection
Yes
Active tampering alarm
Yes
Security algorithms
HTTPS
Intelligent Video Surveillance (IVS) system features
Human detection, Line crossing detection, Moving object, Vehicle detection
Pixel counter
Yes
Digest authentication
Yes
Management features
Power
Power source type
PoE
Power consumption (typical)
11 W
Power consumption (max)
29 W
Operational conditions
Operating temperature (T-T)
-40 - 60 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
183 mm
Depth
464 mm
Height
183 mm
Weight
3.2 kg
Sustainability
Compliance certificates
Electromagnetic Compatibility (EMC), Trade Agreements Act (TAA)
Packaging content
Number of cameras
1
Cables included
LAN (RJ-45)
Manual
Yes
Other features
