Introduction
Experience exceptional image quality in all lighting conditions with this PTZ camera. Reuse existing mounting accessories for a cost-efficient upgrade to the latest AI-powered analytics and Axis technologies.
Superior surveillance in all light conditions
AXIS Q6325-LE offers outstanding 2 MP and features an extremely light-sensitive ½” sensor to deliver clear, bright images and better handling of shadows. Lightfinder 2.0 and Forensic WDR provide details even in challenging light conditions. Plus, OptimizedIR enables surveillance in total darkness. With 31x optical zoom, you can easily follow fast-moving objects. And Axis Zipstream, with support for AV1, H.264, and H.265, significantly lowers bandwidth and storage requirements. Dynamic power mode, together with low power profile, reduces power demands by up to 30% in certain temperature ranges. Furthermore, this camera offers support for audio with a midspan (sold separately) and four I/O ports.
AI-powered with advanced analytics
Built on ARTPEC-9, the latest Axis system-on-chip, this AI-based camera features a deep learning processing unit (DLPU) to run advanced features and powerful analytics on the edge. It also delivers valuable metadata, facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. For instance, it comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and different types of vehicles. Autotracking 2 allows for active object tracking, and an orientation aid enables dynamic text overlays for quick orientation. In addition, chameleon masking safeguards privacy.
Robust with strong cybersecurity
AXIS Q6325-LE includes Axis?Edge?Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access.?And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations. This IP66-, IK10-, NEMA 4x, and NEMA TS2-rated device is both impact and weather-resistant. Furthermore, a midspan is available (sold separately) with support for fiber connection, PoE, audio, I/O, and smart restart, allowing for cost-effective installation and long-distance connection.
Performance
Type
IP security camera
Placement supported
Indoor & outdoor
Connectivity technology
Wired
PTZ control
Yes
PTZ modes
Preset point
Tour recording
Yes
Preset points
Yes
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Infrared (IR) cut-off filter
Yes
Certification
EMC
EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, CISPR 35, EAC, EN 50121-4
Australia/New Zealand: RCM AS/NZS CISPR 32 Class A
Canada: ICES-3(A)/NMB-3(A)
Japan: VCCI Class A
Korea: KS C 9835, KS C 9832 Class A
USA: FCC Part 15 Subpart B Class A
Railway: IEC 62236-4
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN 62471 risk group 2, IEC 60825-1 Class 1
IEC/EN 62262 IK10, IEC/EN 60529 IP66, IEC/EN 60529 IP67, NEMA 250, Type 4X, NEMA TS 2 (2.2.7–2.2.9), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, ISO 21207 (Method B), ISO 12944-6 C5
NIST SP500-267
ETSI EN 303 645, BSI IT Security Label, FIPS 140
Design
Form factor
Dome
Mounting type
Ceiling
Product colour
Black, White
Housing material
Aluminium
Protection features
Impact resistant, Weather resistant
International Protection (IP) code
IP66, IP67
IK code
IK10
Weatherproof
Yes
Camera
Minimum illumination
0.008 lx
Lens viewing angle, horizontal
60.6°
Lens viewing angle, vertical
36.5°
Tilt angle range
-20 - 90°
Tilt speed
550 °/sec
Pan range
0 - 360°
Pan speed
550 °/sec
Camera shutter speed
1/111000 - 1/2 s
Panoramic camera
Signal-to-Noise Ratio (SNR) (panoramic camera)
55 dB
Image sensor
Number of sensors
1
Optical sensor size
25.4 / 2 mm (1 / 2")
Progressive scan
Yes
Sensor type
CMOS
Lens system
Zoom capability
Yes
Optical zoom
31x
Digital zoom
12x
Number of lenses
1
Zoom speed
1 s
Focal length range
6.91 – 214.64
Auto focus
Yes
Night vision
Night vision
Yes
Night vision distance
300 m
LED type
IR
Infra-red wavelength
850 nm
Video
Maximum resolution
1920 x 1080 pixels
Video formats supported
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Supported graphics resolutions
320 x 180
Frame rate
60 fps
Video streaming
Yes
Image quality adjustment
Brightness, Contrast, Sharpness
Text caption overlay
Yes
Bit rate control
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Network
Ethernet LAN
Yes
Ethernet interface type
Fast Ethernet, Gigabit Ethernet
Networking standards
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3bt
Supported network protocols
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Storage
Card reader integrated
Yes
Compatible memory cards
SD, SDHC, SDXC
Flash memory
8192 MB
Internal memory
4096 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Security
Security algorithms
256-bit AES-XTS, EAP-TLS, MSCHAPv2, PEAP
Intelligent Video Surveillance (IVS) system features
Line crossing detection, Moving object
Power
Power consumption (typical)
13.7 W
Power consumption (max)
51 W
Operational conditions
Operating temperature (T-T)
-50 - 55 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 100%
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
239 mm
Depth
239 mm
Height
291 mm
Weight
4.4 kg
Sustainability
Compliance certificates
REACH, RoHS
Packaging content
Other features
Doesn't contain
CFR, PVC/BFR
