Product Details
Display
Display diagonal
190.5 cm (75")
Display brightness
450 cd/mē
Display resolution
3840 x 2160 pixels
Anti-glare screen
Yes
HD type
4K Ultra HD
Panel type
IPS
Native aspect ratio
16:9
Contrast ratio (typical)
1200:1
Contrast ratio (dynamic)
30000:1
Response time
8 ms
Touchscreen
Yes
Touch technology
Multi-touch
Touchscreen type
Infrared
Number of simultaneous touchpoints
40
Touch system response time
10 ms
Working area
1649.7 x 927.9 mm
Surface material
Tempered glass
Haze rate
72%
Low Blue Light technology
Yes
Hardness
9H
Technology
Infrared (IR)
Computer system
Operating system installed
Android
Operating system version
11
Built-in processor
Yes
Processor architecture
ARM Cortex-A55
Processor cores
4
User memory
32 GB
RAM capacity
4 GB
Graphics card family
ARM
Audio
Built-in speaker(s)
Yes
Number of built-in speakers
2
Speaker power
20 W
Network
Wi-Fi
Yes
Bluetooth
Yes
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 2.0 ports quantity
1
USB connector type
USB Type-A, USB Type-B
USB 2.0 Type-B Touch ports quantity
2
HDMI ports quantity
3
USB Type-C ports quantity
1
HDMI version
2.0
DisplayPort version
1.2
DisplayPorts quantity
1
Ethernet LAN (RJ-45) ports
1
VGA (D-Sub) ports quantity
1
Line-in
Yes
Line-out
Yes
OPS slot
1
S/PDIF out port
Yes
Headphone connectivity
3.5 mm
RS-232 ports
1
Ergonomics
Product colour
Black
VESA mounting
Yes
Panel mounting interface
600 x 400 mm
Wall mountable
Yes
Performance
Ambient light sensor
Yes
Power
Power consumption (typical)
135 W
Power consumption (standby)
0.5 W
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
System requirements
Security updates end date
30/08/2026
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
20 - 85%
Storage temperature (T-T)
-10 - 60 °C
Storage relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
1705.7 mm
Depth
90.2 mm
Height
1032.3 mm
Weight
50.4 kg
Packaging data
Package width
1880 mm
Package depth
230 mm
Package height
1160 mm
Package weight
66.5 kg
Quantity per pack
1 pc(s)
Packaging content
Cables included
HDMI, Power, USB Type-A to USB Type-B, USB Type-C, VGA
Remote control included
Yes
Mounting kit
Yes
Stylus included
Yes
Number of stylus pens
2
Sustainability
Sustainability certificates
ENERGY STAR
Information
| Part Number: | 9H.F9TTB.DE1 |
