Product Details
Scanning
Maximum scan size
215.9 x 355.6 mm
Optical scanning resolution
600 x 600 DPI
Enhanced scan resolution
1200 x 1200 DPI
Colour scanning
Yes
Duplex scanning
Yes
Greyscale levels
256
ADF scan speed (b/w, A4)
30 ppm
Design
Scanner type
ADF scanner
Product colour
White
Display
LCD
Display diagonal
7.11 cm (2.8")
Touchscreen
Yes
Colour display
Yes
Control type
Buttons, Touch
Built-in display
Yes
Performance
Sensor type
Dual CIS
Scan to
FTP, PC, SMB
Scan drivers
SANE, TWAIN, WIA
Scanning noise level
62 dB
Paper handling
Scanning media types supported
Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size
A4
ISO A-series sizes (A0...A9)
A4
Card thickness (max)
1.24 mm
Paper tray media weight
51.8 - 128 g/m²
Ports & interfaces
USB port
Yes
USB connector type
USB Type-C
Power
Power supply type
AC/USB
Power consumption (typical)
10 W
Power consumption (standby)
2 W
Power consumption (off)
0.1 W
Network
Wi-Fi
Yes
Wi-Fi standards
802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms
64-bit WEP, 128-bit WEP, EAP-TLS, EAP-TTLS, SMTP-AUTH, SNMPv3, SSH, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPA3-PSK, WPA3-SAE
IPv6 support
Yes
Packaging data
Quantity per pack
1 pc(s)
Package width
369 mm
Package depth
158 mm
Package height
200 mm
Package weight
3.46 kg
System requirements
Windows operating systems supported
Windows 10, Windows 11
Mac operating systems supported
Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Weight & dimensions
Width
288 mm
Depth
101 mm
Height
85 mm
Weight
1.42 kg
Packaging content
Cables included
USB
Information
| Part Number: | ADS1800WZU1 |
