Introduction
High-Performance, Professional Desktop Document Scanner
The ADS-4700W professional desktop document scanner has been designed to keep up with the fast pace of your business while simplifying operational processes.
Fast and reliable
With its large 80-sheet ADF, 40ppm scanning capability and 2-sided (duplex) scanning up to 80ipm, the ADS-4700W has been designed to keep up with the fast pace of your business.
Simple and intuitive
In addition to the user-friendly interface, one touch scanning and a large, 10.9cm touchscreen, you can automate your scanning with one-touch shortcuts to streamline work processes.
Convenient connectivity options
Connect your way with convenient options available, including USB 3.0, USB host, Wi-Fi and ethernet.
Advanced image capture and processing
With Optical Character Recognition (OCR) to transform paper documents to actionable data, the ADS-4700W makes image capture and processing effortless and cuts down your document preparation time.
At your side support
Wherever you are in Australia, Brother offers free product support for the lifetime of your product.
High-performance scanning tools backed by Brother
ScanEssentials is a high-performance scanning tool that allows you to not only scan documents, but also create workflows and save them securely to your network without fuss.
Industry recognised software
The availaibility of Kofax and NewSoft at your fingertips maximises your post-scanning productivity with software that integrates seamlessly with your scanner.
Scanning
Maximum scan size
215.9 x 355.6 mm
Optical scanning resolution
600 x 600 DPI
Enhanced scan resolution
1200 x 1200 DPI
Colour scanning
Y
Duplex scanning
Y
Input colour depth
48 bit
Output colour depth
24 bit
Output greyscale depth
8 bit
Greyscale levels
256
ADF scan speed (b/w, A4)
40 ppm
ADF scan speed (colour, A4)
40 ppm
Duplex ADF scan speed (b/w, A4)
80 ipm
Duplex ADF scan speed (colour, A4)
80 ipm
Design
Scanner type
ADF + Sheet-fed scaner
Product colour
Black, White
Display
LCD
Display diagonal
10.9 cm (4.3")
Touchscreen
Y
Colour display
Y
Control type
Touch
Built-in display
Y
Performance
Sensor type
Dual CIS
Light source
LED
Scan file formats
JPEG,PDF,TIFF
Daily duty cycle (max)
6000 pages
Maximum duty cycle
120000 pages per month
Scan to
E-mail Server, FTP, File, HTTP, PC, SMB
Scan drivers
ISIS,TWAIN,WIA
Ultrasonic sensor
Y
Scanning noise level
59 dB
Input capacity
Auto document feeder (ADF) input capacity
80 sheets
Paper handling
Scanning media types supported
Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper
Long-paper mode
Y
Maximum ISO A-series paper size
A4
Legal
Y
Media thickness (min)
0.28 mm
Card thickness (max)
1.32 mm
Paper tray media weight
40 - 200 g/m²
Maximum scan width
21.6 cm
Maximum scan length
5 m
Ports & interfaces
USB port
Y
USB version
2.0/3.2 Gen 1 (3.1 Gen 1)
Power
Power supply type
AC
Power consumption (typical)
26 W
Power consumption (standby)
2.1 W
Power consumption (off)
0.1 W
Sleep mode
Y
Power consumption (sleep)
1.7 W
Output voltage
24 V
Output current
1.9 A
Auto power off
Y
Network
Wi-Fi
Y
Wi-Fi standards
802.11b,802.11g,Wi-Fi 4 (802.11n)
Ethernet LAN
Y
Security algorithms
64-bit WEP, 128-bit WEP, 802.1x RADIUS, EAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, HTTPS, SMTP-AUTH, SNMPv3, SSL/TLS, TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA3, WPS
IPv6 support
Y
Supported network protocols
DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP, RA, ICMPv6
Packaging data
Quantity per pack
1 pc(s)
Package width
391 mm
Package depth
243 mm
Package height
320 mm
Package weight
3.46 kg
System requirements
Windows operating systems supported
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 x64,Windows 8.1,Windows 8.1 x64
Mac operating systems supported
Y
Linux operating systems supported
Y
Server operating systems supported
Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 90%
Certificates
Certification
GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0
Weight & dimensions
Width
299.5 mm
Depth
215.9 mm
Height
190.5 mm
Weight
2.75 kg
