Introduction
Create customised, durable labels in many colour combinations and widths with this feature-rich high-speed label printer. Design labels on your PC, Mac, tablet or smartphone then print using wired or wireless network connectivity, or USB. Include barcodes, logos and other images, frames and text, and link to existing data in your spreadsheet to easily print many labels at once. Advanced cutter with easy peel feature ensures efficient labelling. Optional rechargeable battery base, touch panel display unit and Bluetooth interface offers a total mobile labelling solution.
- Create durable labels up to 36mm in width
- High speed and high resolution printing
- Wired network & Wi-Fi to print labels from several devices at once, including tablets/smartphones
- Advanced cutter with easy label peel function
- Include images, barcodes and frames on your labels
- Connect to data contained in spreadsheets to batch print many labels at once.
Other features
Spare part retention
5 year(s)
Country of origin
China
Label memory
99 label(s)
Date & time printing
Y
Design
Built-in display
Yes
Product colour
Black
Housing material
Plastic
Logistics data
Pallet gross height
19 cm
Pallet gross weight
300.6 kg
Master (outer) cases per pallet
30 pc(s)
Master (outer) cases per pallet layer
6 pc(s)
Layers per pallet
5 pc(s)
Products per pallet
90 pc(s)
Technical details
Pallet type
800 x 1200 mm
Harmonized System (HS) code
84433210
PC connection
USB 2.0
Sustainability certificates
ENERGY STAR
Printing
Print technology
Thermal transfer
Colour
N
Maximum resolution
360 x 360 DPI
Print speed
60 mm/sec
Maximum print height
3.2 cm
Minimum print length
4 mm
Vertical printing
Y
Rotated printing
Y
Maximum print length
1 m
Ports & interfaces
Connectivity technology
Wired & Wireless
Ethernet LAN
Y
Wi-Fi
Y
Wi-Fi standards
Wi-Fi 4 (802.11n)
USB port
Y
USB 2.0 ports quantity
1
Wi-Fi Direct
Y
Optional connectivity
Bluetooth
Performance
Page description languages
ESC P
Internal memory
6 MB
Built-in barcodes
CODABAR (NW-7),Code-128 Codabar Library,Code-39 Library,EAN128,EAN13,EAN8,GS1 COMPOSITE,GS1 DataBar,GS1 DataBar Expanded,ISBN-2,ISBN-5,ITF,MicroPDF417,POSTNET,QR Code,UPC-A,UPC-E
Number of fonts
4
Tape type
TZe
Tape width
3.6 cm
Image formats supported
GIF, JPG, PNG, TIF, WMF
Power
Number of batteries supported
1
Auto power off
Y
Weight & dimensions
Width
118 mm
Depth
192 mm
Height
146 mm
Weight
1.51 kg
Packaging data
Package width
165 mm
Package depth
266 mm
Package height
333.3 mm
Package weight
2.77 kg
Packaging content
Cables included
USB
Drivers included
Y
Warranty card
Y
Manual
Y
