Introduction
Rugged 2" mobile receipt printer with Bluetooth and Wi-Fi
Offering the highest print speed in its class, and a range of connectivity options for iOS, Android mobile devices, and Windows desktop, the RJ-2050 is built for the toughest environments. The easy-to-read LCD display along with easy-to-load rolls make the RJ-2050 the ideal mobile printer for your business.
On-demand printing
Leave receipts with your customers in a timely manner on completion of work, or when items are delivered. Increase the efficiency of your mobile operatives within field service/sales, retail, public safety, emergency services logistics, warehousing or manufacturing.
Designed for tough jobs
With an IP54 rating against dust and moisture, and 2.5 metre drop protection, the RJ-2050 can withstand the rigours of daily use. This can help reduce the downtime caused by damaged equipment.
Wi-Fi, Bluetooth and USB connectivity
The RJ-2050 has a range of integrated connectivity options including Bluetooth (with support for Apple MFi). Connect to your Wi-Fi network or set the printer to use Wireless Direct mode where a wireless network is unavailable. For Windows based PC's a USB port is provided for reliable connectivity.
Integration into legacy systems
For maximum compatibility with legacy systems, the RJ-2050 supports ZPL II and CPCL emulations. Alternatively use the Brother ESC/P printer language to access, modify and print templates in the printer's flash memory which were previously designed and uploaded from your PC.
SDK's for iOS, Android and Windows devices
Easily add printing within your existing apps and software by harnessing the power of one of the Brother SDK's (Software Development Kits) available. Use the Brother B-PAC SDK for Windows based programs, or one of the Brother Print SDK's for iPhone, iPad or Android devices.
Packaging data
Features
Country of origin
China
Built-in barcodes
AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, ITF, MaxiCode, Micro QR Code, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages
CPCL-native,ESC P,ZPL II
Flash memory
32 MB
RAM capacity
0.032 GB
Design
Display diagonal
6.1 cm (2.4")
Product colour
Black
Built-in display
Y
Display type
LCD
Packaging content
Batteries included
Yes
Quick start guide
Y
Logistics data
Products per pallet
150 pc(s)
Pallet gross height
14 cm
Pallet gross weight
225.4 kg
Master (outer) cases per pallet
50 pc(s)
Layers per pallet
5 pc(s)
Technical details
Master (outer) cases per pallet layer
10 pc(s)
Pallet type
800 x 1200 mm
Harmonized System (HS) code
84433210
Printing
Maximum resolution
203 x 203 DPI
Print speed
6 ips
Print speed
152 mm/sec
Print technology
Direct thermal
Type
Mobile printer
Paper handling
Maximum roll diameter
4 cm
Supported paper width
58 mm
Maximum printing width
5.4 cm
Maximum media length
100 cm
Media thickness
0.058 - 0.09 mm
Ports & interfaces
USB port
Y
USB 2.0 ports quantity
1
USB connector
Mini-USB Type-B
Bluetooth
Y
Bluetooth version
2.1+EDR
Connectivity technology
Wired & Wireless
Bluetooth profiles
BIP,HCRP,OPP,SPP
Standard interfaces
Bluetooth, USB 2.0, Wireless LAN
Network
Ethernet LAN
N
Wi-Fi
Y
Wi-Fi standards
802.11b,802.11g,Wi-Fi 4 (802.11n)
Security algorithms
64-bit WEP,128-bit WEP,EAP-FAST,EAP-TLS,EAP-TTLS,LEAP,PEAP,WEP,WPA,WPA2-PSK
Power
Battery technology
Lithium-Ion (Li-Ion)
Battery voltage
7.2 V
Operational conditions
Operating temperature (T-T)
-10 - 50 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
0 - 95%
System requirements
Windows operating systems supported
Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64
Mobile operating systems supported
Android 4.0, Android 4.1, Android 4.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, iOS 6.0, iOS 6.1, iOS 7.0, iOS 7.1, iOS 7.2, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Weight & dimensions
Width
122 mm
Depth
100 mm
Height
57 mm
Weight
465 g
Other features
International Protection (IP) code
IP54
Rechargeable
Y
Wi-Fi Direct
Y
Mobile printing technologies
Apple AirPrint
