Introduction
Empower your workforce
Tackle the most challenging environments with Brother's 4" mobile label and receipt printer.
Our RJ-4230B mobile printer is fast, compact and extremely rugged. It empowers workers to operate in any environment with speed, accuracy and efficiency.
It has built-in Bluetooth connectivity, printing up to 4" width receipts, quotes, tickets, invoices and labels on demand.
Reliable Connectivity
Provides multiple connectivity options for use in different environments, with USB and Bluetooth (low energy) with MFI capabilities and passive NFC.
Robust Design
The RJ-4230B is our toughest yet, with an IP54 rating and drop tested up to 2.1 metres, providing the ultimate in durability.
Easy to deploy
Using the new Mobile Deploy App, update your printer remotely from any location.
Easy to use
The LCD screen with menu options makes it easy to program as well as a backlight that ensures you can see it in dark conditions.
Seamless Integration
Printer drivers are available for Windows OS and software development kits can be downloaded to support Android and iOS operating systems.
Customisation
We have a wide range of accessories made to suit any environment. See next page.
Brother Font Manager
Brother Font Manager can be used to convert and download fonts in characters or languages not supported by built-in fonts. These can then be stored on a RJ printer and recalled later when printing receipts and labels.
Packaging data
Features
Country of origin
China
Flash memory
64 MB
RAM capacity
0.256 GB
Packaging content
Logistics data
Products per pallet
168 pc(s)
Pallet gross height
16.6 cm
Pallet gross weight
244.2 kg
Master (outer) cases per pallet
56 pc(s)
Layers per pallet
7 pc(s)
Technical details
Master (outer) cases per pallet layer
8 pc(s)
Pallet type
800 x 1200 mm
Harmonized System (HS) code
84433210
Printing
Maximum resolution
203 x 203 DPI
Print speed
5 ips
Print speed
127 mm/sec
Print technology
Direct thermal
Type
Mobile printer
Paper handling
Maximum roll diameter
5.8 cm
Supported paper width
45 - 113 mm
Maximum printing width
10.4 cm
Maximum media length
3 m
Ports & interfaces
USB port
Y
USB 2.0 ports quantity
1
USB connector
Mini-USB Type-B
Bluetooth
Y
Bluetooth version
4.2
Connectivity technology
Wired & Wireless
Bluetooth profiles
GATT,HCRP,OPP,SPP
Near Field Communication (NFC)
Y
Standard interfaces
Bluetooth, NFC, USB 2.0
Network
Design
Product colour
Black
Built-in display
Y
Display type
LCD
Power
Power source type
Battery, DC
AC input voltage
110/220 V
AC input frequency
50 - 60 Hz
Battery technology
Lithium-Ion (Li-Ion)
Battery recharge time
4 h
Operational conditions
Operating temperature (T-T)
-20 - 55 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
System requirements
Windows operating systems supported
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro x64,Windows 8.1 x64
Weight & dimensions
Width
153 mm
Depth
159 mm
Height
68 mm
Weight
850 g
Other features
International Protection (IP) code
IP54
Rechargeable
Y
