Product Details
Introduction
Ultra-fast model takes production scanning to the next level
Optimised for customers who require exceptional high-speed productivity, superior image quality and dependable feeding performance, this A3 scanner has been created to excel in demanding environments
Productivity
Ultra-efficient scanner outputs up to 280 images per minute
Reliability
Robust, durable paper feed and transport rollers can deliver up to 70,000 scans per day
Image quality
Advanced image-processing tools deliver consistently crisp, clear, high-quality images
Scanning
Maximum scan size
305 x 432 mm
Optical scanning resolution
600 x 600 DPI
Colour scanning
Y
Duplex scanning
Y
Output colour depth
24 bit
ADF scan speed (b/w, A3)
145 ppm
ADF scan speed (colour, A3)
145 ppm
Duplex ADF scan speed (b/w, A4)
290 ipm
Duplex ADF scan speed (colour, A4)
290 ipm
Design
Scanner type
Sheet-fed scanner
Product colour
Black, White
Built-in display
Y
Performance
Sensor type
CIS
Light source
RGB LED
Daily duty cycle (max)
70000 pages
Scanning noise level
54 dB
Input capacity
Standard input capacity
500 sheets
Paper handling
Long-paper mode
Y
Maximum ISO A-series paper size
A3
Auto Document Feeder (ADF) media weight
20 - 209 g/m²
Ports & interfaces
USB port
Y
USB version
3.2 Gen 2 (3.1 Gen 2)
Standard interfaces
RJ-45,USB 3.2 Gen 1 (3.1 Gen 1)
Power
Power supply type
AC
Power consumption (typical)
66.5 W
Power consumption (standby)
3.5 W
AC input frequency
50 - 60 Hz
Input voltage
220 - 240 V
Technical details
Harmonized System (HS) code
84716070
Network
Ethernet LAN
Y
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Operating relative humidity (H-H)
20 - 80%
Operating temperature (T-T)
50 - 95 °F
Weight & dimensions
Width
480 mm
Depth
569 mm
Height
315 mm
Weight
25 kg
Information
| Part Number: | 3149C003 |
