Introduction
The Cisco 900 Series ISRs deliver integrated security and threat defense, protecting networks from both known and new Internet vulnerabilities and attacks. These powerful, fixed-configuration routers provide secure broadband and Metro Ethernet and wireless LTE WAN connectivity. Service providers offering both managed Ethernet and wireless LTE WAN services can deploy them in customer locations as CPE. Centralized and remote management capabilities are available through web-based tools and Cisco IOSŪ Software for full visibility and control of network configurations at the remote site.
The 900 Series ISRs simplify the deployment of Ethernet WAN services, with end-to-end Operations, Administration, and Maintenance (OA&M), Service-Level Agreement (SLA) monitoring and verification, and configuration management.
The Cisco 900 Series ISRs come with a 4-port managed switch, providing LAN ports to connect multiple devices.
Technical details
Harmonized System (HS) code
85176990
WAN connection
Ethernet WAN
Y
DSL WAN
Y
SIM card slot
N
3G/4G USB modem compatibility
N
Network
Networking standards
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1x
Ethernet interface type
Gigabit Ethernet
Cabling technology
10/100/1000Base-T(X)
Ethernet LAN data rates
10,100,1000 Mbit/s
VLAN support
Y
Multicast support
Y
Traffic control
Y
Auto MDI/MDI-X
Y
Policy-based routing
Y
Number of users
50 user(s)
Differentiated services (DiffServ) supported
Y
DSL features
Management features
Web-based management
Y
Quality of Service (QoS) support
Y
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
USB ports quantity
1
USB version
2.0
Protocols
Routing protocols
BGP,EIGRP,OSPF
DHCP client
Y
DHCP server
Y
Security
Security algorithms
3DES,128-bit AES,192-bit AES,256-bit AES,DES,SSL/TLS
Firewall
Y
MAC address filtering
Y
Access Control List (ACL)
Y
Network address translation (NAT)
Y
Features
Flash memory
2048 MB
Internal memory
1024 MB
Internal memory type
DRAM
Plug and Play
Y
Safety
IEC 60950-1, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950.1
Design
Product colour
Black
LED indicators
Y
Power
Power consumption (typical)
30 W
Power source type
AC
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Output voltage
12 V
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 4570 m
Weight & dimensions
Width
259.1 mm
Depth
177.8 mm
Height
28 mm
Weight
1.2 kg
