Product Details
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
MIB support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ap, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3z
Full duplex
Yes
VLAN support
Yes
Number of VLANs
4094
Data transmission
Switching capacity
256 Gbit/s
Forwarding rate
190.48 Mpps
MAC address table
32000 entries
Jumbo frames support
Yes
Jumbo frames
9198
Security
DHCP features
DHCP snooping
Access Control List (ACL)
Yes
Multicast features
Multicast support
Yes
Design
Rack mounting
Yes
Product colour
Grey
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 90%
Operating altitude
0 - 3000 m
Weight & dimensions
Width
445 mm
Depth
445 mm
Height
44 mm
Logistics data
Harmonized System (HS) code
85176990
Information
| Part Number: | C9300-48T-M |
