Product Details
Introduction
SFP Transceivers are compliant with the Multi-Source Agreement (MSA) ensuring compatibility with a wide range of networking equipment. Select your choice or Copper or Fiber versions that support Fast Ethernet, Gigabit and 10G Ethernet speeds.
Performance
Harmonized System (HS) code
85369010
SFP transceiver type
Fiber optic
Maximum data transfer rate
1000 Mbit/s
Interface type
SFP
Multi-mode fiber (MMF) supported
Y
Fiber optic connector
LC
SFP transceiver standard
SX
Wavelength
850 nm
Networking standards
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u
Cabling technology
1000BASE-SX
Auto MDI/MDI-X
Y
Features
Hot-Plug support
Y
Certification
MSA
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
10 - 80%
Storage relative humidity (H-H)
10 - 85%
Weight & dimensions
Width
13.4 mm
Depth
56.5 mm
Height
8.5 mm
Information
| Part Number: | MA-SFP-1GB-SX |
