Product Details
Introduction
Compatibility information:
Cisco Room Bar Pro
Cisco Room Kit EQ
Cisco Room Kit EQX
Cisco Codec Pro (over HDMI only)
Cisco Board Pro 55/75 G2
Camera
Camera type
Single camera
Zoom capability
Yes
Optical zoom
12x
Digital zoom
5x
Combined zoom
60x
Focal length range
1.8 - 3.6 mm
Horizontal field of view
80.5°
Vertical field of view
49.2°
White balance
Auto, Manual
Focus adjustment
Auto/Manual
Closest focusing distance
1 m
PTZ control
Yes
Video
HD type
4K Ultra HD
Maximum video resolution
3840 x 2160 pixels
Maximum frame rate
60 fps
Resolution at capture speed
1920x1080@60fps, 3840x2160@30fps
Supported video modes
1080p, 2160p
Design
Product colour
Black
Tilt angle range
-25 - 90°
Pan range
-170 - 170°
Ports & interfaces
HDMI ports quantity
1
Power over Ethernet (PoE) ports quantity
1
Ethernet LAN (RJ-45) ports
1
Power
Power source type
PoE
DC input voltage
42.5 - 57 V
Input current
0.5 A
Power consumption (typical)
12 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
20 - 90%
Storage relative humidity (H-H)
10 - 90%
Network
Ethernet LAN data rates
10,100,1000 Mbit/s
Weight & dimensions
Width
165 mm
Depth
176 mm
Height
196 mm
Weight
2.3 kg
Information
| Part Number: | CS-CAM-RVPTZ-C= |
