Product Details
Introduction
The Cisco Firepower 1100 series security appliances are a standalone modular security services platform. They are capable of running multiple security services simultaneously and so are targeted at the data center as a multiservice platform. See Product ID Numbers for a list of the product IDs (PIDs) associated with the Firepower 1100 series.
Data transmission
Firewall throughput
2200 Mbit/s
IPSec VPN throughput
1.2 Gbit/s
Maximum firewall connections
400000
Maximum firewall connections per second
100000
Performance
Built-in processor
Y
Processor family
Intel
Processor cores
16
Network
Wi-Fi
N
Security
Stateful Packet Inspection (SPI)
Y
Protocols
Supported network protocols
SMTP
Management features
URL filtering
Y
Ports & interfaces
Connectivity technology
Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
Ethernet LAN (RJ-45) ports
8
Console port
RJ-45
Number of console ports
1
SFP module slots quantity
4
Storage
Storage media type
SSD
SSD capacity
200 GB
Design
Rack mounting
Y
Form factor
1U
Power
AC input voltage
100-240 V
AC input frequency
50/60 Hz
Input current
2 A
Power consumption (max)
100 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-25 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Operating altitude
0 - 3000 m
Weight & dimensions
Width
268.7 mm
Depth
436.9 mm
Height
43.7 mm
Information
| Part Number: | FPR1140-NGFW-K9 |
