Product Details
Introduction
What’s new with Wi-Fi 7?
Along with a massive boost to speed, Wi-Fi 7 also introduces 320 MHz ultra-wide bandwidth, 4096-QAM, Multi-RU, and Multi-Link Operation, which all together make your wireless experience more reliable and efficient than ever before.
What’s the difference between Wi-Fi 5,
Wi-Fi 6 and Wi-Fi 7?
Wi-Fi 5 provided a sizeable jump in wireless throughput. And although Wi-Fi 6 provided 37% faster speeds, it was designed with efficiency improvements in mind.
Wi-Fi 7 brings a generation of higher throughput - 480% more than previous generations. A Wi-Fi 7 router, for example, will open up your entire home to the latest online experiences thanks to backwards compatibility.
Features
2.4 GHz
Yes
5 GHz
Yes
6 GHz
Yes
Maximum data transfer rate (2.4 GHz)
720 Mbit/s
Maximum data transfer rate (5 GHz)
2880 Mbit/s
Maximum data transfer rate (6 GHz)
5760 Mbit/s
Ethernet LAN data rates
10,100,1000,10000 Mbit/s
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.3bt
Automatic channel selection
Yes
Maximum Tx power (2.4 GHz)
23 dBmW
Maximum Tx power (5 GHz)
21 dBmW
Maximum Tx power (6 GHz)
21 dBmW
Security
Number of SSID supported
24
Management features
Web-based management
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
Power
Power over Ethernet (PoE)
Yes
Design
Placement
Ceiling, Wall
Product colour
White
Antenna
Antenna type
Internal
Antenna direction type
Omni-directional
Packaging content
Quantity per pack
1 pc(s)
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Information
| Part Number: | DAP-E9560 |
