Product Details
Introduction
Eaton 9PX Gen2 extended battery module (EBM), 240V, Rack/tower, 3U, Rack-mounting kit included
Features
Battery voltage
12 V
Battery capacity
5 Ah
Number of batteries included
20 pc(s)
Product colour
Black, Silver
Rack capacity
3U
Power consumption (average operating)
210 W
Efficiency
96.5%
Efficiency (ECO mode)
98.9%
Input power factor
0.99
Noise level
37 dB
Ports & interfaces
AC outlet types
C13 coupler, C19 coupler
USB port
Yes
RS-232 ports
1
Battery
Battery technology
Sealed Lead Acid (VRLA)
Battery capacity
5 Ah
Battery voltage
12 V
Typical backup time at half load
7.1 min
Automatic battery test
Yes
Battery technology
Sealed Lead Acid (VRLA)
Design
Form factor
Rackmount/Tower
Rack capacity
3U
Product colour
Black
LED indicators
Yes
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Certificates
Compliance certificates
BSMI, CE, Electromagnetic Compatibility (EMC), KCC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UKCA, WEEE, cULus
Certification
IEC/EN 62040-1
IEC/EN 62040-2
IEC/EN 62040-3
Compliance certificates
BSMI, CE, Electromagnetic Compatibility (EMC), KCC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UKCA, WEEE, cULus
Certification
IEC/EN 62040-1
IEC/EN 62040-2
IEC/EN 62040-3
CE
cULus
UKCA
Cm
Ukr
RCM
Packaging content
Rack mount kit
Yes
Cables included
Output power cable, USB cable
Quick installation guide
Yes
Sustainability
Sustainability certificates
ENERGY STAR
Sustainability certificates
ENERGY STAR
Weight & dimensions
Width
440 mm
Depth
684 mm
Height
130 mm
Weight
43.1 kg
Weight
62 kg
Width
440 mm
Height
130 mm
Depth
670 mm
Information
| Part Number: | 9PXEBM240RT3UG2 |
