Product Details
Features
Battery voltage
72 V
Product colour
Black, Silver
Rack capacity
1U
UPS topology
Double-conversion (Online)
Output power capacity
2.2 kVA
Output power
2200 W
Waveform
Pure sine
Input operation voltage (min)
176 V
Input operation voltage (max)
276 V
Input frequency
40/70 Hz
Output operation voltage (min)
200 V
Output operation voltage (max)
240 V
Output frequency
50/60 Hz
Number of input phases
1
Efficiency
93.5%
Noise level
40 dB
Ports & interfaces
AC outlet types
C13 coupler, C19 coupler
Power plug
C20 coupler
AC outlets quantity
10 AC outlet(s)
USB port
Y
USB 2.0 ports quantity
1
RS-232 ports
1
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery voltage
72 V
Battery technology
Lithium-Ion (Li-Ion)
Design
Form factor
Rackmount/Tower
Rack capacity
1U
Product colour
Black, Silver
Display type
LCD
LED indicators
Y
Certification
IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CB report (TUV) / EAC
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating temperature (T-T)
0 - 40 °C
Technical details
Sustainability certificates
CE, ENERGY STAR
Compliance certificates
CE
Weight & dimensions
Width
438 mm
Depth
603 mm
Height
42 mm
Weight
17.4 kg
Weight
17.4 kg
Width
438 mm
Height
42 mm
Depth
603 mm
Packaging data
Rack mount kit
Y
Certificates
Compliance certificates
CE
Certification
IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CB report (TUV) / EAC
Sustainability
Sustainability certificates
ENERGY STAR
Information
| Part Number: | 9PXEBM72RT1U-L |
