Product Details
Introduction
The bezel just got smaller.
The 2770L 27” touchscreen offers up to a 70% reduction in the bezel compared to similar models.
Built-in speakers and integrated IO.
Place it on a desktop, mount it on a wall or configure the 2770L to fit your space with VESA-compatibility. Built-in speakers and integrated IO.
Durable, energy efficient touchscreen.
Scratch-resistant glass surface. IK07 impact resistant. ES8.0 certified for greater energy efficiency.
Navigate the OSD directly on the touchscreen.
We have made it easier to manage your On-Screen Display (OSD) controls – Now you can use the touchscreen or the controls you are used to on the rear side of the monitor.
Power
Energy efficiency class (SDR)
E
Energy consumption (SDR) per 1000 hours
18 kWh
Energy efficiency scale
A to G
Power consumption (typical)
19 W
Power consumption (standby)
0.5 W
Power consumption (off)
0.16 W
Power consumption (PowerSave)
16.5 W
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power supply type
External
Display
Display diagonal
68.6 cm (27")
Display resolution
1920 x 1080 pixels
HD type
Full HD
Native aspect ratio
16:9
Display technology
LED
Panel type
TFT
Touchscreen
Yes
Touchscreen technology
Projected capacitive system
Touch technology
Multi-touch
Number of simultaneous touchpoints
10
Display brightness (peak)
300 cd/m²
Display brightness (typical)
270 cd/m²
Response time
14 ms
Anti-glare screen
Yes
Screen shape
Flat
Supported graphics resolutions
640 x 400, 640 x 480 (VGA), 720 x 400, 800 x 500, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Contrast ratio (typical)
1000:1
Maximum refresh rate
60 Hz
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Display number of colours
16.7 million colours
Digital horizontal frequency
30 - 82 kHz
Digital vertical frequency
50 - 75 Hz
Performance
NVIDIA G-SYNC
No
AMD FreeSync
No
Multimedia
Built-in speaker(s)
Yes
Built-in camera
No
Number of speakers
2
RMS rated power
4 W
Design
Market positioning
Business
Product colour
White
Ports & interfaces
Built-in USB hub
Yes
USB hub version
2.0
USB upstream port type
USB Type-A, USB Type-B
Number of USB Type-B upstream ports quantity
1
USB Type-A downstream ports quantity
2
USB Touch port
Yes
USB Touch ports quantity
1
VGA (D-Sub) ports quantity
1
HDMI
Yes
HDMI ports quantity
1
DisplayPorts quantity
1
Ergonomics
VESA mounting
Yes
Panel mounting interface
100 x 100 mm
Cable lock slot
No
Height adjustment
No
On Screen Display (OSD)
Yes
On Screen Display (OSD) languages
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 95%
Weight & dimensions
Width (without stand)
626.2 mm
Depth (without stand)
372.8 mm
Height (without stand)
43.8 mm
Weight (without stand)
6.3 kg
Packaging data
Package width
703 mm
Package depth
136 mm
Package height
489 mm
Package weight
9.45 kg
Information
| Part Number: | E266381 |
