Introduction
The Elo Touch Solutions 1523L 15-inch touchmonitor is well-suited to meet the durability and aesthetic requirements for a variety of high traffic retail and hospitality interactive solutions. Retail peripheral accessories include an encryptable MSR, NFC/RFID for contactless payments, webcam, and rear-facing display bracket.
The edge to edge flat glass style of the 1523L brings a sleek, modern feel to any application. It is available in two touchscreen technologies, IntelliTouch Zero-Bezel surface acoustic wave, and IntelliTouch Pro projected capacitive with anti-glare surface coating, supporting 10-touch interaction right out of the box.
Both touch technologies provide a stable "drift-free" operation with outstanding image clarity, resolution and light transmission - for an accurate touch response and vivid images.
Display
Display diagonal
38.1 cm (15")
Display resolution
1024 x 768 pixels
Display technology
LCD
Native aspect ratio
4:3
Aspect ratio
4:3
Response time
16 ms
Display brightness
270 cd/m²
Contrast ratio (typical)
700:1
Viewing angle, horizontal
160°
Viewing angle, vertical
140°
Display viewable area (HxV)
229.1 x 305.1 mm
Digital horizontal frequency
31 - 80 kHz
Digital vertical frequency
56 - 75 Hz
LED backlight
Y
Supported graphics resolutions
640 x 480 (VGA),1024 x 768 (XGA),720 x 400,800 x 600 (SVGA)
Viewable size, horizontal
30.5 cm
Viewable size, vertical
22.9 cm
Display number of colours
16.2 million colours
Design
Performance
Touchscreen technology
Projected capacitive system
Built-in speaker(s)
Y
RMS rated power
4 W
Number of speakers
2
Mean time between failures (MTBF)
50000 h
Ports & interfaces
USB 2.0 ports quantity
2
DVI port
Y
DVI-D ports quantity
1
Ergonomics
Panel mounting interface
75 x 75 mm
Wall mountable
Y
Power
Power consumption (typical)
10.5 W
Power consumption (standby)
1.2 W
Power consumption (off)
0.2 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 95%
Weight & dimensions
Width (with stand)
358.1 mm
Depth (with stand)
199.1 mm
Height (with stand)
318.5 mm
Weight (with stand)
4.2 kg
Dimensions (W x D x H) with stand
358.1 x 199.1 x 318.5 mm
Packaging data
Package width
447 mm
Package depth
207 mm
Package height
380 mm
Package weight
7 kg
