Product Details
Performance
Sound pressure level (printing)
53 dB
Tape cutting
Automatic
Character pitch
22.6,16.9 cpi
Mean time between failures (MTBF)
260000 h
Mean cycles between failures (MCBF)
70000000
Cutter
Y
Certification
VCCI-Class A, FCC-Class A, CE, AS / NZS 3548
Logistics data
Pallet weight (UK)
0 g
Pallet gross weight
0 g
Products per pallet layer
16 pc(s)
Products per pallet layer (UK)
24 pc(s)
Products per pallet (UK)
168 pc(s)
Pallet length (UK)
120 cm
Pallet width (UK)
100 cm
Pallet height (UK)
2.5 m
Pallet gross width
80 cm
Pallet gross length
120 cm
Pallet gross height
2.5 m
Products per pallet
112 pc(s)
Technical details
Box contents
Label paper roll, Main unit, PS-180, Panel label for horizontal installation, Paper exit guide, Paper roll spacer, Power switch cover, User manual
Interface
USB 2.0, Ethernet interface (100 Base-TX / 10 Base-T)
Harmonized System (HS) code
84433210
Printing
Print technology
Direct thermal
Colour
N
Maximum resolution
203 x 203 DPI
Print speed
150 mm/sec
Printing characters
Barcode
Paper handling
Autocutter
Y
Half-cutter
N
Maximum roll diameter
9 cm
Media thickness
0.06 - 0.08 mm
Supported paper width
80 mm
Autocutter durability
2 million cuts
Ports & interfaces
Connectivity technology
Wired
Ethernet LAN
Y
USB port
Y
USB 2.0 ports quantity
1
Design
Product colour
Grey
Power
AC input voltage
24 V
Power consumption
1800 mA
Operational conditions
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
5 - 45 °C
Storage temperature (T-T)
-10 - 50 °C
Weight & dimensions
Width
140 mm
Depth
148 mm
Height
203 mm
Weight
1.9 kg
Packaging data
Quantity per pack
1 pc(s)
Package width
193 mm
Package depth
250 mm
Package height
240 mm
Package weight
2.8 kg
Packaging content
Manual
Y
Other features
Safety
UL, CSA, TÜV
Buffer size
4 KB
Character sets
ANK
Country of origin
China
Information
| Part Number: | C31C412465 |
