Introduction
Faster, better inkjet technology
Inkjet technology means that not only are printouts more detailed (600dpi compared to 180dpi for existing models), they’re around twice as fast too, with a print speed of 100mm/s (23.2lps) compared to 43mm/s (13.5lps) for previous models.
Low TCO
Epson has managed to incorporate inkjet technology into this new model while retaining a similar low total cost of ownership to previous dot matrix printers.
Simple maintenance
The ink cartridges have an easy-install design ideal for busy retail counters, as well as drop-in paper roll for quick loading, and the ink formulation used offers better water and light resistance than dot matrix, so receipts and documents will last longer.
Backwards compatible
To make upgrading from existing models incredibly easy, the TM-J7700 is fully backwards-compatible with the TM-J7500 and has exactly the same footprint, so it can simply be swapped in. However, to integrate smoothly with the latest ePOS systems, the model offers both USB and Ethernet connection options.
Printing
Colour printing
N
Print speed
98 mm/sec
Print speed (graphic)
98 mm/sec
Print speed (receipt)
98 mm/sec
Print speed (slip)
85 mm/sec
Printing characters
Text, Graphic, Barcode
Character sets
ANK
Alphanumeric memory
95
Print technology
Inkjet
Type
POS printer
Paper handling
Supported paper width
58 - 83 mm
Media thickness
0.06 - 0.09 mm
Maximum paper size (slip)
230 x 297 mm
Ports & interfaces
USB port
Y
USB 2.0 ports quantity
1
USB connector
USB Type-B
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Interface
USB 2.0, Ethernet interface (100 Base-TX / 10 Base-T), Drawer kick-out, Customer Display
Network
Ethernet LAN
Y
Ethernet LAN data rates
10,100 Mbit/s
Wi-Fi
N
Features
Sound pressure level (printing)
55 dB
Mean time between failures (MTBF)
180000 h
Half-cutter
N
Autocutter durability
1.5 million cuts
Country of origin
China
Printer receipt unit life
3700000000 lines
Printer slip unit life
5000000 lines
Safety
TÜV, TÜV (EN60950-1)
Certification
CE, EN55024, EN55032 Class A, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-11
Design
Power
Power source type
DC
AC input voltage
24 V
Power consumption (standby)
70000 mA
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
-20 - 40 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
20 - 85%
Weight & dimensions
Width
251 mm
Depth
260 mm
Height
188 mm
Weight
5.8 kg
Packaging data
Cables included
AC
Quantity per pack
1 pc(s)
Package width
355 mm
Package depth
390 mm
Package height
310 mm
Package weight
7.87 kg
Logistics data
Pallet weight (UK)
0 g
Pallet gross weight
0 g
Products per pallet
36 pc(s)
Products per pallet (UK)
36 pc(s)
Technical details
Font styles
ANK
Box contents
CD Manual, Ink Cartridge, PS-180, Power cable, Power switch cover, Roll paper, Setup guide, USB cable, User manual (CD)
Safety warning
Contains 2,4,7,9-tetramethyldec-5-yne-4,7-diol. May produce an allergic reaction.
Always follow the information on the product label.
Harmonized System (HS) code
84433210
Other features
Paper dimensions
58 mm - 83 mm
Mean cycles between failures (MCBF)
5000000
