Introduction
Fast, versatile, robust
Exceptional quality, versatility, connectivity and durability, plus auto-cutter, de-curler and Qi-compatible wireless charging.
Compact and stylish, the TM-P80IIAC is lighter, yet more robust, than ever, and is packed with advanced features designed to deliver fast, high quality results. Providing outstanding flexibility, reliability, connectivity and ease-of-use, it’s the perfect choice for busy, on-the-go environments such as retail, hospitality and in-vehicle applications.
Ideal for demanding on-the-go environments, such as hospitality and in-vehicle applications, the all-new TM-P80IIAC is compact, stylish and even lighter than its predecessor. Now offering enhanced impact resistance, plus protection from dust and water ingress to IP54 standards, it can handle barcodes and 2D symbols, and includes an auto-cutter and de-curler module to ensure flat, clean receipts. With USB-C connectivity, plus support for Bluetooth 5.0 “classic” and low-energy modes, it provides excellent range, seamless pairing and reliable all-day battery life, while its Wi-Fi 5 capability delivers excellent wireless performance, plus a Wi-Fi “Direct” mode, enabling direct connection of up to 8 devices without the need to connect to a network or hotspot. Plus, as the TM-P80II AC is Qi-enabled, charging is effortless, quick and reliable.
Printing
Print speed (receipt)
100 mm/sec
Printing characters
Graphic, Barcode, 2D barcode, Text
Colour
N
Maximum resolution
203 x 203 DPI
Print speed
65 mm/sec
Print technology
Thermal
Type
Mobile printer
Paper handling
Supported paper width
80 mm
Paper loading type
Top & front
Printing media thickness
75 µm
Maximum printing width
8 cm
Ports & interfaces
Near Field Communication (NFC)
Yes
USB port
Y
USB connector
USB Type-C
Bluetooth
Y
Bluetooth version
5.0
Connectivity technology
Wired & Wireless
Interface
Bluetooth, USB Type-C
Features
Built-in barcodes
Code 128 (A/B/C), CODABAR (NW-7), UPC-E, UPC-A, GS1 DataBar, EAN8, GS1-128, EAN13, Code 39, Data Matrix, Code 93, ITF, MaxiCode, PDF417
Mean time between failures (MTBF)
120000 h
Paper save function
Yes
Print head life
50 km
Cutter
Y
Sound pressure level (printing)
53 dB
Country of origin
Philippines
Power
Battery life (max)
34 h
Power source type
DC
AC input voltage
7.2 V
Battery capacity
1950 mAh
Technical details
Font styles
ANK, BIG5, GB18030-80, JIS X0208-90, KSC-5601C, Traditional Chinese, Simplified Chinese
Paper size roll paper
79.50 ± 0.50 (W) mm x dia 51.00 mm
Box contents
Battery (OT-BY20), Belt clip, Main unit, Quick Start Guide, Roll paper, Setup guide, USB cable, Warranty document
Print speed
Max. 100 mm/sec at 203 x 203 DPI ( printing width80 mm)
Technology
Thermal Line
Other features
Design
Operational conditions
Operating temperature (T-T)
-15 - 50 °C
Storage temperature (T-T)
-25 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
0 - 90%
Weight & dimensions
Width
105 mm
Depth
153.4 mm
Height
66.9 mm
Weight
504 g
Packaging data
Cables included
USB
Quantity per pack
1 pc(s)
Package width
220 mm
Package depth
165 mm
Package height
115 mm
Package weight
795 g
Logistics data
Products per pallet
320 pc(s)
Products per pallet layer
40 pc(s)
Pallet gross width
80 cm
Pallet gross length
120 cm
Pallet gross height
2.23 m
Products per pallet (UK)
384 pc(s)
Products per pallet layer (UK)
48 pc(s)
Pallet length (UK)
120 cm
Pallet height (UK)
2.23 m
