Product Details
Printing
Maximum resolution
203 x 203 DPI
Colour
No
Print speed
300 mm/sec
Print speed (receipt)
300 mm/sec
Printing characters
Graphic, Barcode, 2D barcode, Text
Paper handling
Roll dimensions
Roll 57mm, Roll 80mm
Supported paper width
58 - 80 mm
Ports & interfaces
Near Field Communication (NFC)
Yes
Interface
USB 2.0-A, USB Type-C, Ethernet interface (100 Base-TX / 10 Base-T), Micro SD Card Slot, USB 2.0 Type B (Service Only), Wireless LAN IEEE 802.11a/b/g/n/ac, Drawer kick-out, Wi-Fi Direct, Bluetooth, Near Field Communication (NFC)
Features
Built-in barcodes
Code 128 (A/B/C), CODABAR (NW-7), UPC-E, UPC-A, GS1 DataBar, EAN8, GS1-128, EAN13, Code 39, Data Matrix, Code 93, ITF, MaxiCode, PDF417
Mean time between failures (MTBF)
360000 h
Cutter
Yes
Autocutter durability
2.2 million cuts
Paper save function
Yes
Tablet charge & sync
Yes
Print head life
150 km
Mounting position
Horizontal/Vertical
Wall mountable
Yes
Built-in sensors details
Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor, Paper Jam Sensor, Receipt near-end sensor, Receipt paper sensor
Sound pressure level (printing)
53 dB
Country of origin
Philippines
Weight & dimensions
Depth
127 mm
Width
127 mm
Height
130 mm
Weight
1.3 kg
Technical details
Font styles
ANK, Traditional Chinese, Simplified Chinese
Paper size roll paper
79.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm
57.50 ± 0.50 (W) mm x dia 83.00 mm
Voltage
24 V
Compliance certificates
CE
Power consumption
Mean:0.1 A, Mean Receipt unit: approx.1.8 A
Box contents
AC adapter, AC cable, Main unit, Paper roll spacer, Quick Start Guide, Roll paper, Setup guide
Print speed
Max. 300 mm/sec at 203 x 203 DPI ( printing width80 mm)
Technology
Thermal Line
Other features
Buffer size
4 KB
Mean cycles between failures (MCBF)
65000000
Print head life (receipt unit)
150 km
Power
AC input voltage
100 - 230 V
AC input frequency
50 - 60 Hz
Operational conditions
Operating temperature (T-T)
5 - 45 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Packaging data
Quantity per pack
1 pc(s)
Package width
210 mm
Package depth
240 mm
Package height
210 mm
Package weight
2.39 kg
Logistics data
Products per pallet
112 pc(s)
Products per pallet layer
14 pc(s)
Products per pallet (UK)
160 pc(s)
Products per pallet layer (UK)
20 pc(s)
Information
| Part Number: | C31CK50151 |
