Introduction
Fast, compact, versatile
The TM-m30III mobile POS receipt printer offers a range of excellent features, including enhanced connectivity and reliability.
Based on a stylish and ultra-compact design, and with a host of advanced features, Epson’s TM-m30III is ideal for environments where quick, simple and reliable receipt printing is essential. A perfect combination of mobility, connectivity, reliability and ease-of-use, it’s designed to meet the needs of a wide range of growing businesses.
Even more feature-rich than its predecessors, this addition to Epson’s highly popular TM-m30 series features an ultra-small footprint and super-sleek design, and delivers easy, cost-effective and reliable receipt printing in any environment where space is an issue. Including not only a USB Type-C PD (Power Delivery) connector, the TM-m30III (Wireless model) also features integral Wi-Fi and Bluetooth functionality, while its antibacterial coating provides protection against liquids to IPX2 standards, making it ideal for tough environments such as kitchens. Also featuring a paper near-end detection system, it’s great for kiosks and self-checkouts, and its superior de-curling mechanism means that it’s perfect for receipts that need a signature. Now supporting Android and Windows as well as iOS, the TM-m30III comes with links to video guides that make set-up and configuration fast and easy.
Printing
Colour
No
Print speed
300 mm/sec
Print speed (receipt)
300 mm/sec
Printing characters
Graphic, Barcode, 2D barcode, Text
Maximum resolution
203 x 203 DPI
Print technology
Thermal
Type
POS printer
Paper handling
Roll dimensions
Roll 57mm, Roll 80mm
Supported paper width
58 - 80 mm
Ports & interfaces
Near Field Communication (NFC)
Yes
USB port
Yes
Bluetooth
Yes
Connectivity technology
Wired & Wireless
Interface
USB 2.0-A, USB Type-C, Ethernet interface (100 Base-TX / 10 Base-T), Micro SD Card Slot, USB 2.0 Type B (Service Only), Wireless LAN IEEE 802.11a/b/g/n/ac, Drawer kick-out, Wi-Fi Direct, Bluetooth, Near Field Communication (NFC)
Features
Built-in barcodes
Code 128 (A/B/C), CODABAR (NW-7), UPC-E, UPC-A, GS1 DataBar, EAN8, GS1-128, EAN13, Code 39, Data Matrix, Code 93, ITF, MaxiCode, PDF417
Mean time between failures (MTBF)
360000 h
Cutter
Yes
Autocutter durability
2.2 million cuts
Paper save function
Yes
Tablet charge & sync
Yes
Print head life
150 km
Mounting position
Horizontal/Vertical
Wall mountable
Yes
Built-in sensors details
Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor, Paper Jam Sensor, Receipt near-end sensor, Receipt paper sensor
Sound pressure level (printing)
53 dB
Country of origin
Philippines
Network
Ethernet LAN
Yes
Wi-Fi
Yes
Weight & dimensions
Depth
127 mm
Width
127 mm
Height
130 mm
Weight
1.3 kg
Design
System requirements
Windows operating systems supported
Yes
Mac compatibility
Yes
Mobile operating systems supported
Android, iOS
Pre-installed software
Server Direct Print
Technical details
Font styles
ANK, Traditional Chinese, Simplified Chinese
Paper size roll paper
79.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm
Voltage
24 V
Compliance certificates
CE
Power consumption
Mean:0.1 A, Mean Receipt unit: approx.1.8 A
Box contents
AC adapter, AC cable, Main unit, Paper roll spacer, Quick Start Guide, Roll paper, Setup guide
Print speed
Max. 300 mm/sec at 203 x 203 DPI ( printing width80 mm)
Technology
Thermal Line
Other features
Buffer size
4 KB
Mean cycles between failures (MCBF)
65000000
Print head life (receipt unit)
150 km
Power
AC input voltage
100 - 230 V
AC input frequency
50 - 60 Hz
Operational conditions
Operating temperature (T-T)
5 - 45 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Packaging data
Quantity per pack
1 pc(s)
Package width
127 mm
Package depth
127 mm
Package height
130 mm
Package weight
2.2 kg
