Introduction
The capable, affordable POS printer with versatile connectivity
Engineered for a balance of speed, reliability and affordability in a compact package, the TM-T20IV thermal receipt printer is purpose-built for taking on the demanding POS needs of today’s businesses. This versatile printer supports traditional PC-POS and mPOS systems and features two built-in connectivity options, allowing for exceptional flexibility and productivity: (1) USB with serial connectivity and (2) USB with serial and Ethernet connectivity. The TM-T20IV is built for productivity—with print speeds up to 250 mm/sec, an intuitive status LED and paper savings of up to 30 percent1, it’s the ideal solution for keeping your POS workflow moving quickly and efficiently. The printer is backed by a 2-year limited warranty, with extended service plan options available up to a total of 5 years of continuous coverage2, giving you Epson’s world-class service and support for your peace of mind.
Printing
Colour
No
Maximum resolution
203 x 203 DPI
Print speed
250 mm/sec
Character size
1.25 x 3 mm
Character density
22.6 cpi
Printing characters
Graphic
Print technology
Thermal
Type
POS printer
Paper handling
Printing media thickness
53 - 75 µm
Maximum roll diameter
8.3 cm
Supported paper width
80 mm
Features
Safety
UL, CSA, TÜV
Built-in barcodes
CODABAR (NW-7), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, GS1-128, ITF, UPC-A, UPC-E
Mean time between failures (MTBF)
360000 h
Cutter
Yes
Autocutter durability
2 million cuts
Print head life
150 km
Wall mountable
Yes
Receive buffer
4 KB
Built-in sensors details
Paper End Sensor, Paper Near End Sensor
Sound pressure level (printing)
55 dB
Country of origin
Philippines
Ports & interfaces
USB port
Yes
USB 2.0 ports quantity
1
USB connector
USB Type-B
Serial interface
Yes
Serial interface type
RS-232
Connectivity technology
Wired
Optional connectivity
Ethernet, Wireless LAN
Interface
RS-232, Drawer kick-out, USB 2.0
Network
Design
Power
Power source type
DC
Power consumption (printing)
27.2 W
AC input voltage
100 - 230 V
AC input frequency
50/60 Hz
DC output voltage
24 V
Power consumption (standby)
0.96 W
Operational conditions
Operating temperature (T-T)
5 - 45 °C
Storage temperature (T-T)
-10 - 50 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
System requirements
Windows operating systems supported
Yes
Mobile operating systems supported
Android, iOS
Weight & dimensions
Width
140 mm
Depth
199 mm
Height
146 mm
Weight
1.7 kg
Packaging data
Cables included
AC
Quantity per pack
1 pc(s)
Package width
195 mm
Package depth
235 mm
Package height
280 mm
Package weight
2.65 kg
Packaging content
Technical details
Compliance certificates
Federal Communications Commission (FCC), ICES
Safety warning
UL62368-1, CAN/CSA C22.2 No.62368-1
Font styles
ANK
Paper size roll paper
79.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm
Voltage
24 V
Power consumption
Standby:0.1 A, Mean:1.8 A
Box contents
AC adapter, C1, Cable cover, EURO AC cable, Main unit, Paper roll spacer
Technology
Thermal Line
Other features
Mean cycles between failures (MCBF)
60000000
Buffer size
4 KB
Logistics data
Products per pallet
112 pc(s)
Products per pallet layer
16 pc(s)
Pallet gross width
80 cm
Pallet gross length
120 cm
Pallet gross height
2.11 m
Products per pallet (UK)
168 pc(s)
Products per pallet layer (UK)
24 pc(s)
Pallet length (UK)
120 cm
Pallet height (UK)
2.11 m
